© 2001 Edelbrock Corporation
Brochure No. 63-0048
Page 8 of 8
Rev 1/02
Edelbrock replacement manifolds are designed to maintain high vacuum at cruise throttle position and sharp throttle response with minimum throttle
opening. Unnecessary demands on the added performance will affect mileage.
REFERENCE SYMBOLS & NOMENCLA
TURE
MANIFOLD INSTALLATION AND
CARBURETOR SELECTION SIMPLIFIED
To simplify the selection of all parts necessary for a complete intake manifold selection, Edelbrock has developed a system which includes packaged
accessory pieces intended to allow “one stop” shopping for manifold installations. Under each listed manifold there is a coding. These letters refer to
the “symbol nomenclature” listed on this page and in the Edelbrock catalog. This nomenclature gives specific information about what parts will be
needed for each Edelbrock manifold installation. Specific carburetor features are also identified, especially with regard to OEM emissions equipment.
SYMBOL NOMENCLATURE:
A. Carb will work with non-EGR or pre-emission control system.
B. Carb will work with EGR systems.
C. Adapter for this Carb supplied with this manifold.
D. No Carb lever for the auto. trans. kickdown rod.
F. Use manifold-to-manifold base gasket same year/model as vehicle, unless base gasket supplied with Carb.
H. Carb has provision for evaporative canister.
I. Carb has no provision for evaporative canister.
J. Do not use Ford variable venturi OEM 2-bbl. Carb.
K. Carb requires stud, nut, and washer kit #8008 (5/16-18 x 1-3/8") or #8024 (5/16-18 x 1-3/4"). Determine length needed before installing.
L. Carb requires #8003 (1/4" rod extension), #8004 (5/16" rod extension), or #8022 (cable extension) for Chrysler auto.trans. Determine size
needed before installing.
M. Ford EGR adapter needed.
N. Carb will accept factory cruise control.
O. Carb has manual choke only
P. Carb is NOT a stock replacement part.
Edelbrock Corporation.
2700 California Street • Torrance, California 90503
IF YOU HAVE ANY QUESTIONS REGARDING THIS PRODUCT OR INSTALLATION,
PLEASE CONTACT OUR TECHNICAL DEPARTMENT
From 7:00 am To 5:00 pm, PST, Monday through Friday at:
Edelbrock Corporation. 2700 California Street, Torrance, CA 90503
Tech Telephone Number: (800) 416-8628 or (310)-782-2900
Tech department Fax (310)-972-2730
Email: Edelbrock@Edelbrock.com
