English
Compass
Your detector includes an internal
8-point
Compass that will continuously
display your current direction of travel:
N, NE, E, SE, S, SW, W or NW.
Calibrating the Compass
NOTE
Before using it for the first time, you must calibrate the compass to
provide accurate indications of direction. See page 7 for instructions
on using the Program mode to select Set Compass.
Calibration allows the compass electronics to measure and store
information about the magnetic fields generated by your vehicle.
The compass will remain accurately calibrated as long as your detector is
mounted in the same place in your vehicle. If you change the location where
the unit is mounted or move it to another vehicle, you must recalibrate the
compass.
The compass temporarily may not provide accurate readings if you are inside
a building or enclosure, or are close to a large metal tractor/trailer, truck, or
train. Once you are away from such a location, the compass will work
correctly again.
NOTE
When the instructions direct you to drive in two circles, a large parking
lot is the most convenient place to do so. It does not matter what
direction your vehicle is pointing when you start the circles, which
direction you go to make the circles, and it does not have to be exactly
two circles. You do NOT have to make perfect circles. You can drive in
any pattern, as long as you make two complete turns. Four three-point
turns, two small squares, or any two complete loops will work as well as
two circles. It does not matter what size the circles are, if your speed is
constant, or how fast you make the circles [but less than two minutes].
Please be careful when making the circles and watch for other traffic.
Intro Operation Customer
Assistance
Warranty
N
otice
in Icons
condary Icons
Intro Operation Customer
Assistance
Warranty
Notice
in Icons
condary Icons
8-Point
Compass
N
S
W
NW
SW
E
NE
SE
Tone Visual Display
One beep Compass not set…
Please try again…
NOTE
If you do not press the Set/City button within two minutes after beginning
the set compass process, compass calibration will automatically terminate.
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Compass n...
Please tr...
Terminate
Set Compa...
Set Compass
Drive in...
Press SET...
Calibrate Compass
Compass
Set!
Compass Set
NW h
Direction of Travel
To Calibrate the Compass Using Program Mode
(See Page 7 For Instructions on Using Program Mode)
In Program mode, go to
Set Compass.
Tone
Visual Display
None Set Compass
Press and release the Set/City button
to begin setting the compass.
One beep Drive in 2 circles…
Press SET when
done…
Within two minutes, drive your
vehicle in a circle twice, then press
the Set/City button again.
Three beeps Compass Set!
For two seconds
followed by direction
of travel (N, NE, E,
SE, S, SW, W or NW)
Press and release either the Select/Dim
button to proceed to the next user
mode or the Program/Mute button
to exit Program mode.
None None
Program/Mute Button
Select/Dim Button
Set/City
Button
