4. User Selectable Programming Options
The Ungo MS2106 features a user selectable programming table allowing simple
adjustments to match the user’s preferences.
User Programming Options Table
4.1 User Programmable Options
1.
Arming Mode:
Selects whether or not the system will automatically Arm when
ignition is turned off.
2.
Auto Rearming:
Selects whether or not the security system will rearm if no
activity is detected after Remote Disarming. (If Passive Door Locking feature
was selected during installation, the system will also relock the doors.)
Automatic Rearming only takes place if the system was Armed (actively or
passively) for at least 10 seconds and then remotely disarmed.
3.
Arming Chirps:
Selects whether or not the security system will chirp when arm
and disarmed.
4.
Ignition Controlled Door Locking:
Selects whether or not the doors will lock
when the ignition is turned On. Ignition Controlled Door Locks will automatically
lock the doors 10 seconds after the ignition is turned On. To prevent the keys
from being locked inside the vehicle; the security system will not lock the doors
if any of the doors is open when the ignition is turned On.
5.
Ignition Controlled Door Unlocking:
Selects whether or not the security
system the doors will unlock when the ignition is turned Off. Ignition Controlled
Door Unlocking can be configured to unlock all the doors or driver's door only.
6.
Override Code Programming:
Selects the number of times the Valet button
must be depressed to override the system. The Override Code can be any
number between 1 and 15. (Default setting is 1)
1. Arming Mode Active Passive
2. Auto Rearm On Off
3. Arming Chirps Normal Silent
4. Ignition Controlled Door Locking On Off
5. Ignition Controlled Door Unlocking All Doors Driver’s Door Off
6. Override Code Programming
Code Set
7. Remote Start in Valet Mode Enabled Disabled
8. Automatic Starting Disabled
Temperature Start Voltage Start
Steps 7 & 8 are reserved for use with Ungo-Net Start Module.
Feature Button 1 (default) Button 2 Button 3
