Black plate (16,1)
Chevrolet Camaro Owner Manual - 2011
10-16 Vehicle Care
3.6 L V6 Engine Air Cleaner/Filter
Housing Shown (6.2 L V8 Engines
Similar)
3. Loosen the clamp at the duct of
the air cleaner/filter housing.
4. Unlatch the retaining clips on the
air cleaner/filter housing.
5. Lift cover at retaining clip
location high enough to clear
retaining clips and pull cover
outward to remove cover from
the air cleaner/filter housing
hinges.
6. Pull straight up on cover, while
holding the cover remove the air
filter.
7. Inspect or replace the air filter.
See Maintenance Replacement
Parts on page 11‑8.
8. Reverse steps 6 to 1 to install
cover.
{
WARNING
Operating the engine with the air
cleaner/filter off can cause you
or others to be burned. The air
cleaner not only cleans the air; it
helps to stop flames if the engine
backfires. Use caution when
working on the engine and do not
drive with the air cleaner/filter off.
Notice: If the air cleaner/filter is
off, dirt can easily get into the
engine, which could damage it.
Always have the air cleaner/filter
in place when you are driving.
