9-34 Vehicle Care
Replacement Bulbs
Exterior Lamp
Bulb
Number
Back-Up Lamp 921
Fog Lamp Front H11
Headlamp
High Beam
HB3
Headlamp
Low Beam
H11
License Plate Lamp W5WLL
Parking Lamp/Turn
Signal Front
T20
Sidemarker Front
and Rear
194
Taillamp/Turn Signal
Lamp/Stop Lamp
3157K
For replacement bulbs not listed
here, contact your dealer.
Electrical System
Fuses
The wiring circuits in the vehicle are
protected from short circuits by
fuses. This greatly reduces the
chance of damage caused by
electrical problems.
Look at the silver-colored band
inside the fuse. If the band is broken
or melted, replace the fuse. Be sure
to replace a bad fuse with a new
one of the identical size and rating.
There are two fuse blocks in the
vehicle: one in the engine
compartment and one in the
instrument panel.
There is a fuse puller located in the
engine compartment fuse block.
See Engine Compartment Fuse
Block
on page 9‑34
. It can be used
to easily remove fuses from the fuse
block.
Engine Compartment
Fuse Block
To remove the fuse block cover,
squeeze the clips on the cover and
lift it straight up.
The vehicle may not be equipped
with all of the fuses and relays
shown.
Notice: Spilling liquid on any
electrical components on the
vehicle may damage it. Always
keep the covers on any electrical
component.
