Vehicle Axle Ratio Maximum Trailer Weight GCWR*
G2500 Cargo Van 2WD Long Wheelbase
4.8L V8
3.73
4.10
6,200 lbs (2 812 kg)
7,200 lbs (3 266 kg)
12,000 lbs (5 443 kg)
13,000 lbs (5 897 kg)
6.0L V8
3.73
4.10
8,200 lbs (3 719 kg)
10,000 lbs (4 536 kg)
14,000 lbs (6 350 kg)
16,000 lbs (7 257 kg)
G2500 Passenger Van 2WD Short Wheelbase
6.0L V8 3.73 7,600 lbs (3 447 kg) 14,000 lbs (6 350 kg)
6.0L V8 4.10 10,000 lbs (4 536 kg) 16,000 lbs (7 257 kg)
G3500 Cargo Van 2WD Short Wheelbase
4.8L V8
3.73
4.10
6,400 lbs (2 903 kg)
7,400 lbs (3 357 kg)
12,000 lbs (5 443 kg)
13,000 lbs (5 897 kg)
6.0L V8
3.73
4.10
8,400 lbs (3 810 kg)
10,000 lbs (4 536 kg)
14,000 lbs (6 350 kg)
16,000 lbs (7 257 kg)
G3500 Cargo Van 2WD Long Wheelbase
4.8L V8
3.73
4.10
6,100 lbs (2 767 kg)
7,100 lbs (3 221 kg)
12,000 lbs (5 443 kg)
13,000 lbs (5 897 kg)
6.0L V8
3.73
4.10
8,200 lbs (3 719 kg)
10,000 lbs (4 536 kg)
14,000 lbs (6 350 kg)
16,000 lbs (7 257 kg)
G3500 Passenger Van 2WD Short Wheelbase
6.0L V8 3.73 7,600 lbs (3 447 kg) 14,000 lbs (6 350 kg)
G3500 Passenger Van 2WD Long Wheelbase
6.0L V8 3.73 7,300 lbs (3 311 kg) 14,000 lbs (6 350 kg)
*The Gross Combined Weight Rating (GCWR) is the total allowable weight of the completely loaded vehicle and
trailer including any passengers, cargo equipment and conversion. The GCWR for the vehicle should not be
exceeded.
4-30
