6. Undo the clamps on the filter cover. To remove
the cover, pull up on the front and then pull the
cover out.
7. Inspect or replace the engine air cleaner/filter.
Wipe all dust from inside of the housing and
inspect the air cleaner and air outlet duct for cracks,
cuts, and deterioration. The air outlet duct must
be replaced if damaged.
8. Reinstall the filter cover and latch the clamps.
9. Reattach the air outlet duct and tighten the screws
on the clamps that hold the duct in place.
10. Reconnect the crank case ventilation tube.
11. Reconnect the air flow sensor electrical connector.
{CAUTION:
Operating the engine with the air cleaner/filter
off can cause you or others to be burned.
The air cleaner not only cleans the air; it helps
to stop flames if the engine backfires. If it is
not there and the engine backfires, you could
be burned. Do not drive with it off, and be
careful working on the engine with the air
cleaner/filter off.
Notice: If the air cleaner/filter is off, a backfire
can cause a damaging engine fire. And, dirt can
easily get into your engine, which will damage it.
Always have the air cleaner/filter in place when you
are driving.
5-20
