1-6 General Information
Operator Keypad
Display Custom Backlit LCD
Keypad 8 Key with Tactile Feel
Functions Output Status Monitoring, Digital Speed Control,
Parameter Setting and Display and Fault Log
Display
LED Indicators Red/Green for Status
Analog Outputs
Analog Outputs 1 Assignable
Full Scale Range 0 to 10VDC Maximum
Output Conditions 3 conditions plus calibration
(see Analog Output Table)
Relay Outputs
Relay Outputs 1 Assignable
Rated Voltage 115VAC
Rated Current 1 Ampere Maximum
Conditions 10 conditions (see Relay Output Table)
Fault Conditions
Automatic Shutdown 15 conditions (see Fault Code Table)
Watts Loss Data
Total Watts Loss
Catalog No. Horsepower
Input
Voltage
Single Phase
Input
Three Phase
Input
ID101F50-E 0.5 1PH 115 24 N/A
ID10101-E 1.0 1PH 115 42 N/A
ID102F50-E 0.5 3PH 230 16 19
ID10201-E 1.0 3PH 230 28 37
ID10202-E 2.0 3PH 230 52 66
ID10203-E 3.0 3PH 230 66 70
ID10205-E 5.0 3PH 230 70 129
ID10401-E 1.0 3PH 460 N/A 40
ID10402-E 2.0 3PH 460 N/A 67
ID10403-E 3.0 3PH 460 N/A 118
ID10405-E 5.0 3PH 460 N/A 184
