Setting 1 - Passive/Active Arm
1. Passive Arm 1 Flash/Honk The starter disable relay will activate 30
seconds after the ignition is “OFF”.
*2. Active Arm 2 Flashes/Honks The starter disable relay when LOCK
is pressed
1. Turn the ignition key to the “ON” position.
2. Within 10 seconds, press and release the remote transmitter buttons:
LOCK, UNLOCK, LOCK, UNLOCK.
Setting 2 - Passive/Active Lock (setting 1 must be ON)
1. Passive Lock 1 Flash/Honk The doors will automatically lock when
the system arms in the passive mode.
*2. Active Lock 2 Flashes/Honks The doors will ONLY lock/unlock with
the remote transmitter.
1. Turn the ignition key to the “ON” position.
2. Within 10 seconds, press and release the remote transmitter buttons:
UNLOCK, TRUNK, UNLOCK, TRUNK.
Setting 3 - Ignition Auto Locks
1. On 1 Flash LOCK two seconds after the ignition is turned “ON”
and UNLOCK when ignition is turned “OFF”
*2. Off 2 Flashes LOCK/UNLOCK by remote transmitters ONLY
1. Turn the ignition key to the “ON” position.
2. Within 10 seconds, press and release the remote transmitter buttons:
LOCK, TRUNK, LOCK, TRUNK.
*(default setting)
Enter Programming:
1. Make sure ignition is in the OFF position.
2. Turn the ignition key ON - leaving key in the ON position.
3. Press the transmitter button in the appropriate sequence. The parking
lights and the horn (optional) will flash the appropriate option.
NOTE: After ten seconds the system will automatically exit Program Mode.
INSTALL MANUAL REMOTE VEHICLE KEYLESS
PAGE 6
PROGRAMMING
