ALARM STATUS / DIAGNOSTICS
PARK LIGHTS LED FLASHES DIAGNOSTICS / STATUS
3 SLOW FLASHES LED’s ON SOLID SYSTEM IS IN SERVICE MODE.
4 SLOW FLASHES SERIES OF 8 FLASHES NOT SET IN RESERVATION MODE “M” MODELS
5 SLOW FLASHES SERIES OF 5 FLASHES START ATTEMPT WHILE IGNITION IS ON
5 FLASHES SERIES OF 5 FLASHES START ATTEMPT WITH HOOD SWITCH OPEN
6 FLASHES SERIES OF 6 FLASHES START ATTEMPT WITH BRAKE APPLIED
7 FLASHES SERIES OF 7 FLASHES SYSTEM IS IN TACH LOCK OUT (SEE DEALER)
8 FLASHES SERIES OF 8 FLASHES THREE START ATTEMPTS WITH NO START
Diagnostic Mode is a tool that can help trouble shoot a start fault. If the remote starter fails to
start i.e.: the hood is open the park likes will flash a diagnostic code. i.e.: 5 flashes = start
attempt with hood open. If the vehicle does not remote start, count the park light flashes then
compare it to the chart below.
The start fault must be corrected in order for the system to operate correctly. See your dealer
for additional trouble shooting or visit and visit the support page..www.ultrastarters.com
TROUBLE SHOOTING
When I press the start button the vehicle acts like it is going to start but does not?
This issue is most common to a problem with the bypass module. Bypass modules turn your
factory security off so that the remote starter can start the vehicle. Have your dealer reprogram
the bypass module to the vehicle.
When I unlock the doors the windows roll down or the Trunk Pops?
This issue is caused by the length of the unlock pulse. To correct this issue program the system
for short door lock pulses. (125ms)
The alarm activates 30-45 minutes after setting it?
To prevent the vehicles battery from going dead the computer will "hibernate" like your home
computer might. In some vehicles this causes the door pin input to change state. The alarm
detects the change of state and activates. A relay must be installed to isolated the door pin
circuit from the alarm.
The starter motor stays engaged to long when remote started?
Reset then relearn the Tach with the transmission in reverse. If the vehicle is tach learned when
the idle is high the starter motor may "drag". Check your ground connection if issues persist.
PAGE 22
95 SERIES
OWNERS MANUAL
DIAGNOSTICS
Applicated Security Technologies, Inc. ("AST") promises to the original purchaser to repair or replace with a
comparable reconditioned model any AST control module ("module") excluding without limitation the any other
accessories, including but not limited to the antenna, remote, siren and wiring harness, proves to be defective in
workmanship or material under reasonable use during the lifetime of the vehicle it was originally installed,
provided the following conditions have been met: the module was professionally installed and serviced by an
authorized AST dealer; the unit will be professionally reinstalled in the vehicle in which it was originally installed
by an authorized AST dealer; the warranty information card was sent to AST within 10 days of the original
installation date. Any warranty returns include a warranty return authorization number issued by AST, original
bill or sale and be pre-paid shipped directly to AST. After an initial period of 2 years from the date of installation,
AST reserves the right, at its sole discretion, to charge a warranty processing fee of $30.00 USD. AST does not
cover the cost for return freight on warranty items, this cost is the sole responsibility of the purchaser.
All components included with the original packaged unit other than the module, including but not limited to the
siren, antenna and the remote transmitters, carry a one-year warranty from the date of purchase of the same.
Any warranty returns on components must include a warranty return authorization number issued by AST,
original bill or sale and be pre-paid shipped directly to AST. This warranty is non-transferable and is
automatically void if: the original purchaser has not completed the warranty card and mailed it within ten (10)
days of the date of purchase to the address listed on the card; the unit's date code or serial number is defaced,
missing or altered; the unit has been modified or used in a manner contrary to its intended purpose; the unit has
been damaged by accident, unreasonable use, neglect, improper service, installation or other causes not
arising out of defects in materials or construction. The warranty does not cover damage to the unit caused by
installation or removal of the unit. AST, at its sole discretion, will determine what constitutes excessive damage
and may refuse the return of any unit with excessive damage, including, but not limited to, overloading, moisture
and physical damage.
To the maximum extent allowed by law, any and all warranties are excluded by the manufacturer and each
entity participating in the stream of commerce therewith. This exclusion includes but is not limited to, the
exclusion of any and all warranty of merchantability and/or any and all warranty of fitness for a particular
purpose and/or any and all warranty of non-infringement or patents, in the United States of America and/or
abroad. Neither the manufacturer or any entities connected therewith shall be responsible or liable for any
damages whatsoever, including but not limited to, any consequential damages, incidental damages, damages
for loss of time, loss of earnings, commercial loss, loss of economic opportunity and the like. Notwithstanding
the above, manufacturer does offer a limited warranty to replace or repair the control module as describe above.
Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation on
how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This
warranty gives you specific legal rights, and you may also have other rights, which vary State to State.
WARRANTY
PAGE 23
95 SERIES
OWNERS MANUAL
WARRANTY
