Parts of the System
Phaser® 8510/8560MFP Multifunction Product
1-2
Parts of the System
This section includes:
Front View on page 1-2
Side View on page 1-3
Back View on page 1-3
Open View on page 1-4
Front View
Phaser 8510MFP/D Product and
All Phaser 8560MFP Products Phaser 8510MFP/N Product
1. Tray 4 (optional)
2. Tray 3 (optional)
3. Tray 2
4. Tray 1
5. Output tray
6. Exit cover
7. Control panel
8. Document feeder
9. Duplex automatic document feeder
10. Interface cover
11. Side door
12. Front cover release
1. Document cover
8560-001
1
2
3
4
6
9
10
11
12
7
8
5
8560-134
1
