Execute S.M.A.R.T. off-line routine immediately in off-line mode
Execute S.M.A.R.T. Short self-test routine immediately in off-line mode
Execute S.M.A.R.T. Extended self-test routine immediately in off-line mode
Execute S.M.A.R.T. Selective self-test routine immediately in off-line mode
Abort off-line mode self-test routine
Execute S.M.A.R.T. Short self-test routine immediately in captive mode
82h Execute S.M.A.R.T. Extended self-test routine immediately in captive
Execute S.M.A.R.T. Selective self-test routine immediately in captive mode
5.1.2.2 Captive Mode
When executing a self-test in captive mode, the Element SSD executes the self-
test routine after receipt of the command. At the end of the routine the Element
SSD places the results of this routine in the self-test execution status byte and
reports command completion. If an error occurs while the Element SSD is
performing the routine it discontinues its testing, place the results of this routine
in the self-test execution status byte and the DST log page, and complete the
command.
5.1.2.3 S.M.A.R.T. Logs
S.M.A.R.T. logs are intended to enhance S.M.A.R.T. Attribute information by
capturing additional drive details at appropriate times. This information may lead
to improved error detection and reporting capability. The controller supports
S.M.A.R.T. logs, and relevant tests, events, and conditions each have an
associated log. S.M.A.R.T. logs conform to industry-standard structures.
The reported size of each log is reported by the Log Directory (Log 0). Note that
the information returned via S.M.A.R.T. Read Log access to Log 0 is more limited
than that via GP Read Log. Log size is only reported the LSB (max 255 blocks)
when access via S.M.A.R.T. Read Log command; and full 2 bytes (max 65535
blocks) when access via Read Log EXT command.
The frequency at which S.M.A.R.T. logs are updated is the frequency at which
checkpoint information is saved. That frequency is related to data volume, and
can range between approximately 2 seconds and 2 minutes, depending on how
much data is being transferred. Therefore, constant host system IOs cause
check-pointing and S.M.A.R.T. log update relatively frequently (approximately
every 2 seconds); very slow or idle host transaction rates result in check-pointing
and S.M.A.R.T. log update less frequently (worst-case around every 2 minutes).
All logs are non-volatile except as within each of the log description.
