Revision J
#
##
#
:$6?/?2
Print Cartridge Specification HP C6602A
1
Cartridge arrangement 12 vertical nozzles
Vertical dot pitch 0.264 mm (0.0104") or 96dpi.
Cartridge life ~7.0 M Characters @ 16 dots per Character.
Cartridge Colors Black, Red, Blue, Green
7=
7=7=
7=6
66
6*>
*>*>
*>
Paper width: 3.0" ± .02" (76mm ± .5mm)
Paper roll diameter: 4.0" max (101.6mm max)
Paper thickness: .003" - .004" (.07mm - .1mm)
Roll paper core outside Dia. 0.82" - 0.85" (20.8 – 21.6 mm) Dia.
Roll paper core inside Dia. 0.45" - 0.50" (11.4 – 12.7 mm) Dia.
Roll footage: 330 feet - standard grade
300 feet - premium grade
<%7;
<%7;<%7;
<%7;
Form thickness-single part: .003" to .0047" (.076 mm. to .119 mm.)
Form Size (Min): 2.75" high x 2.75" long (69.8 mm. x 69.8 mm.)
Form Size (Max): 8.5" high x 11" long (215.9 mm. x 279.4 mm.)
# Validation lines: Max. 9 lines (1.53") @ 6 lines per inch
Check Basis weight: 24 lbs.
#
##
#
@$2
The POSjet
®
1500 Printer is designed to be AC self-powered in domestic and international markets. The printer is
equipped with a detachable universal input power supply that is designed to operate worldwide without modification.
@$+2
Optionally, the POSjet
®
1500 Printer can be operated with an external 24-volt DC power supply.
1
Print Cartridge Specifications are controlled by Hewlett-Packard and are proprietary. Information here is for
reference only.
