SPECIFICATIONS AND OPERATION
Features two control
switches and two
indicators to indicate
printer status.
Control panel
Plugs into an outlet of
the specified voltage.
Shape of AC power plug
will vary according to
destinations.
AC power cord
Connects the printer
with host computer.
Interface connector
Connects to peripheral units such
as cash drawers, etc.
Do not connect this to a telephone.
Peripheral unit drive circuit connector
Protects the printer from
dust and reduces noise.
Do not open the cover
while printing.
Printer cover
[ TSP200-120/230 ]
2. External Appearance
Fig. 1-2 External Appearance
For connection of the AC adapter.
Never unplug the AC adapter
while the printer is on.
AC adapter cable connector
[ TSP200-24 ]
