112
Icon/item
HiFi SOUND
AUDIO MIX
A/VtDV OUT
NTSC PB
LCD BRIGHT
LCD B. L.
LCD COLOUR
VF BRIGHT
Mode
z STEREO
1
2
——
z OFF
ON
z ON PAL TV
NTSC 4.43
——
z BRT NORMAL
BRIGHT
——
——
Meaning
To play back a stereo tape or dual sound track tape
with main and sub sound (p. 189).
To play back a stereo tape with the left sound or a
dual sound tape with main sound.
To play back a stereo tape with the right sound or a
dual sound track tape with sub sound.
To adjust the balance between the stereo 1 and
stereo 2 (p. 101).
To output digital images and sound in analog
format using your camcorder.
To output analog images and sound in digital
format using your camcorder. (p. 89)
To play back a tape recorded in the NTSC colour
system on a PAL system TV.
To play back a tape recorded in the NTSC colour
system on a TV with the NTSC 4.43 mode.
To adjust the brightness on the LCD screen with the
SEL/EXEC dial.
To set the brightness on the LCD screen normal.
To brighten the LCD screen.
To adjust the colour on the LCD screen, turn and
press the SEL/PUSH EXEC dial.
To adjust the brightness on the viewfinder screen,
turn and press the SEL/PUSH EXEC dial.
POWER
switch
VCR
VCR
VCR
VCR
VCR
CAMERA
MEMORY
VCR
CAMERA
MEMORY
ST1 ST2
VCR
CAMERA
MEMORY
VCR
CAMERA
MEMORY
Note on the playback of the NTSC tapes
When you play back on a Multi System TV, select the best mode while viewing the picture on the TV.
Notes on LCD B.L.
•When you select BRIGHT, battery life is reduced by about 10 percent during recording.
•When you use power sources other than the battery pack, BRIGHT is automatically selected.
To darken To lighten
To get low-
intensity
To get high-
intensity
Changing the menu settings
To darken To lighten
