PART NO. DESCRIPTIONREF NO QTY.
Steering Group
Footnotes
1 2176440 6 BUSHING, Nylon
2 1703508A 1 PLATE, Mounting
3 1928352 4 NUT, Hex Flange Whiz Lock, 3/8-16, Black
4 1722495 1 SHAFT & PINION ASSEMBLY
5 1919314 1 PIN, Cotter, Black
6 1960540 1 PIN, Spring, 5/16 x 2-1/2, Black
7 2860202 1 WASHER, 3/4
8 1666001 1 BUSHING, Metal
9 1931317 2 CARRIAGE BOLT, 1/4-20 x 3/4
10 1722497A 1 SUPPORT ASSEMBLY
11 1960518 2 NUT, Push, 1/4, Black
12 1721736A 1 PLATE, Mounting
13 2828732 2 NUT, Hex KEPS, 1/4-20, Black
14 1722749 1 COVER, Black Rubber
15 1722738 1 STEERING WHEEL
16 1722319 1 CAP, Steering Wheel
17 1723111 1 DASHBOARD
18 1921525 1 CAPSCREW, Hex Head, 1/2-13 x 1-3/4, Black
19 2105386 1 SPACER
20 1723129 1 SPACER
21 1960245 1 CAPSCREW, Hex Head, 1/2-13 x 3, Black
22 1611710 2 RING, Klip, External 3/4, Black
23 1724616 1 AXLE ASSEMBLY,w/Bushings & Lube Fitting
24 1960355 2 NUT, Hex Lock ESNA Heavy, 1/2-13, Black
25 1918431 2 WASHER, 1/2, Black
26 2821133 3 FITTING, Lube
27 1921210 2 CAPSCREW, Hex Head, 3/8-16 x 1, Black
28 1611705 2 SPACER, Powder Metal
29 1722387 1 ROD, Tie
30 1677131 1 SPINDLE & LEVER ASSEMBLY, RH (Lancer LH)
31 1921969 1 CAPSCREW, Hex Head, 3/8-16 1-1/2
32 1960339 2 NUT, Hex Flange Lock, 3/8-16, Black
33 1708236 1 SPACER
34 1677133 1 SPINDLE & LEVER ASSEMBLY, LH (Lancer RH)
35 1702779A 2 BALL JOINT
36 1930645 1 NUT, Hex Flange Lock, 3/8-16, Black
37 1919262 2 NUT, Hex Head, 1/2-20, Black
38 1722504 1 DRAG LINK
39 1930644 1 NUT, Hex Flange Two Way Lock, 1/2-13, Black
40 1724793A 1 SHAFT & GEAR ASSEMBLY
41 1920328 1 CAPSCREW, Hex Head, 1/2-13 x 1-1/2, Black
42 1930591 2 CAPSCREW, Hex Head, 5/16-18 x 3/4
43 1931350 4 CARRIAGE BOLT, 3/8-16 x 1 , Black
44 1935255 6 NUT, Speed, 5/16-18
The above parts group applies to the following Mfg. Nos.:
2005
7
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694772 - Lancer
1694785 - 4416XL
1694786 - Lancer
1694787 - 4416XL
TP 400-4206-01-LN-SM
