Connecting the Machine
30
1
IEEE 802.11b (wireless LAN)
This section lists the settings required for delivering data to network with an
IEEE 802.11b (wireless LAN) connection.
For details about how to specify the settings, see "Interface Settings" and "File
Transfer".
Note
❒ For the Effective Protocol setting, check that the protocol you want to use is
set to [Active].
❒ [IEEE 802.11b] and [LAN Type] are displayed when the wireless LAN interface
board is installed. When both Ethernet and wireless LAN (IEEE 802.11b) are
connected, the selected interface takes precedence.
❒ If Delivery Option is set to [On], check that IPv4 Address is specified.
Menu User Tool Setting Requirements
Interface Settings/Network Machine IPv4 Address Necessary
Interface Settings/Network IPv4 Gateway Address As required
Interface Settings/Network DNS Configuration As required
Interface Settings/Network DDNS Configuration As required
Interface Settings/Network Domain Name As required
Interface Settings/Network WINS Configuration As required
Interface Settings/Network Effective Protocol Necessary
Interface Settings/Network LAN Type Necessary
Interface Settings/Network Permit SNMPv3 Communication As required
Interface Settings/Network Permit SSL/TLS Communication As required
Interface Settings/Network Host Name As required
Interface Settings/
IEEE 802.11b
Communication Mode Necessary
Interface Settings/
IEEE 802.11b
SSID Setting As required
Interface Settings/
IEEE 802.11b
Channel As required
Interface Settings/
IEEE 802.11b
Security Method As required
Interface Settings/
IEEE 802.11b
Transmission Speed As required
File Transfer Delivery Option As required
File Transfer Fax RX File Transmission As required
File Transfer Scanner Resend Interval Time As required
File Transfer Number of Scanner Resends As required
