Parameters Description
Enable Virtual Server Enable Virtual Server.
Private IP This is the LAN client/host IP address that the Public Port
number packet will be sent to.
Note: You need to give your LAN PC clients a fixed/static IP
address for Virtual Server to work properly.
Private Port This is the port number (of the above Private IP host) that the
below Public Port number will be changed to when the packet
enters your LAN (to the LAN Server/Client IP)
Type Select the port number protocol type (TCP, UDP or both). If you
are unsure, then leave it to the default both protocol.
Public Port Enter the service (service/Internet application) port number from
the Internet that will be re-directed to the above Private IP
address host in your LAN
Note: Virtual Server function will have priority over the DMZ
function if there is a conflict between the Virtual Server and the
DMZ settings.
WAN Port Assign the WAN port that you want to bind to the virtual server.
All the packets sending from this WAN port with the assigned
public port will be directed to the assign private IP and private
port.
Comment The description of this setting.
Add Virtual Server Fill in the "Private IP", "Private Port", "Type", “Public Port” and
"Comment" of the setting to be added and then click "Add". Then
this Virtual Server setting will be added into the "Current Virtual
Server Table" below. If you find any typo before adding it and
want to retype again, just click "Clear" and the fields will be
cleared.
Remove Virtual Server If you want to remove some Virtual Server settings from the "
Current Virtual Server Table", select the Virtual Server settings
you want to remove in the table and then click "Delete Selected".
If you want remove all Virtual Server settings from the table, just
click "Delete All" button. Click "Reset" will clear your current
selections.
Click <Apply> at the bottom of the screen to save the above configurations. You can now
configure other advance sections or start using the router (with the advance settings in place)
3.4.3 Special Applications
Some applications require multiple connections, such as Internet games, video conferencing,
Internet telephony and others. In this section you can configure the router to support multiple
connections for these types of applications.
