- 20 -
Device
The shortcut to go to another member switch in the management stack.
4.4 Device Configuration
Panel Display
Network Configuration
IP Address: IP address of this device.
Subnet Mask: Subnet Mask of your network.
Gateway IP: IP address of Gateway.
Device Information
Name: Naming the system (optional).
Contact: Who the System administrator is (optional).
Location: Where the management stack locates (optional).
ëNote
The Network Configuration and Device Information of Master Device in the
management stack will become system parameters automatically.
SWITCH ID
MASTER LED
STATUS LED
Slide-in Modules
RJ-21 VDSL ports
Port Link status LED
