Check if Repeater Mode is shown on the lower left corner. If yes,
Click NEXT.
If not, disconnect the power and go to Connect power to the Wireless Range
Extender
Time Settings: Select your time zone
Click NEXT.
Password Settings:
Set your password (Choose something easy to remember).
Click NEXT.
Press Scan button
The Site Survey list will now show the available Wireless Networks using the factory
default settings.
Click on the selection box behind your Wireless Network.
Click NEXT.
Settings are being saved and next you will see the login screen.
Your Wireless Range Extender (WRE) is now configured. Next you need to adapt
your Wirless Base Station settings in order to use the Wireless Range Extender
(WRE) in your Wireless Network.
