SA1MXX08K/02
MP3 player
Mix 8GB*
Specifications
Picture/Display
• Backlight
• Lines of text: 4
• Resolution: 128 x 64
• Type: LCD
Sound
• Equalizer customizable
• Frequency response: 80 - 18 000 Hz
• Equalizer settings: Funk, Hip Hop, Jazz, Rock,
Techno, Classical
• Signal to noise ratio: > 80 dB
• Channel separation: 35 dB
• Output power (RMS): 2 x 3 mW
Audio Playback
• Compression format: MP3, WAV, WMA
• MP3 bit rates: 8-320 kbps and VBR
• ID3 Tag support: Song title, artist, album
• WMA bit rates: 64-320 kbps
• WMA sample rates: 8, 11.025, 16, 22.050, 32,
44.1, 48 kHz
• MP3 sample rates: 16, 32, 44.1, 48, 11.025, 22.050,
24, 8
kHz
Storage Media
• Built-in memory type: NAND Flash
• Built-in memory capacity: 8 GB
• Mass storage class compliant
• Music memory capacity, MP3: Up to 1800 tracks*
Connectivity
• Headphone: 3.5 mm
• USB: High speed USB 2.0
Convenience
• Function: Keypad lock
• Superscroll
• Battery charging indication: On User Interface
• Volume control
• Firmware upgradeable
Accessories
• Headphones: AY3820
• Quick start guide
Software
• Device manager: to restore and upgrade
Green Specifications
• Lead-free soldered product
System Requirements
• PC OS: Windows 2000 / XP / Vista
• Internet connection: Yes (for access to updated
support documents, manuals, future firmware and
PC software upgrades)
• USB: Free USB port
Power
• Battery capacity: 370 mAh
• Playtime on internal battery: Up to 25 hours
• Battery Type: LI-Polymer
• Rechargeable: Yes, via USB
Dimensions
• Product dimensions (WxDxH): 71 x 14 x 28 mm
• Product weight: 0.029 kg
• Packaging type: D-box
Tuner/Reception/Transmission
• Station presets: 20
• Tuner Bands: FM
Audio Capturing
• Audio file format: WAV
• Built-in microphone: mono
• Voice recording
• FM radio recording
•
Issue date 2009-03-02
Version: 1.0.3
12 NC: 8670 000 50641
EAN: 87 12581 47086 9
© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
* Storage capacity based on 4 minutes per song and 64 kbps WMA or
128 kbps MP3 encoding.
* Actual transfer speed may vary based on your operating system and
software configuration.
* 1GB = 1 billion bytes; available storage capacity will be less.
* Rechargeable batteries have a limited number of charge cycles and
may eventually need to be replaced. Battery life and number of
charge cycles vary by use and settings.
