Activating and deactivating
SLEEP
The sleep timer enables the system to switch off
by itself after a set period of time. The clock time
needs to be set first before the sleep timer can
be used.
● Press SLEEP on the remote
control repeatly to select
desired time before system
shuts off.
➜ Display shows SLEEP and
series of time options for
selection: 60, 45, 30,15, OFF, 60.
Clock/Timer
● To deactivate, press SLEEP on the remote
control once or more until OFF is shown, or
press STANDBY ON on the system or
remote control.
Specifications
AMPLIFIER
Output power ...................................... 2 x 2.5 W RMS
.................................................................. 2 x 2.1 W FTC
(1)
Signal-to-noise ratio .......................... ≥ 62 dBA (IEC)
Frequency response ......... 60 – 16000 Hz ± 3 dB
Impedance loudspeakers......................................... 4 Ω
Impedance headphones ................. 32 Ω – 1000 Ω
(1)
(4 Ω, 125 Hz - 10 kHz, 10% THD)
CD PLAYER
Number of programmable tracks ......................... 20
Frequency range .................................. 63 – 14000 Hz
Signal-to-noise ratio ............................................55 dBA
Channel seperation............................................ ≥ 30 dB
Total harmonic distortion..................................≤ 1.5%
TUNER
FM wave range ...................................87.5 – 108 MHz
AM wave range ..................................530 – 1700 kHz
FM Sensitivity at 75 Ω
– mono, 26 dB signal-to-noise ratio ............ 2.8 µV
– stereo, 46 dB signal-to-noise ratio ........ 61.4 µV
Selectivity ................................................................. ≥ 28 dB
Total harmonic distortion..................................... ≤ 5%
FM Frequency response 63 – 9000 Hz (± 3 dB)
FM Signal-to-noise-ratio .............................. ≥ 50 dBA
TAPE DECK
Frequency response
Normal tape (type I)... 120 – 10000 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I).................................... 48 dBA
Wow and flutter ......................................... ≤ 0.4% DIN
SPEAKERS
Bass reflex system
Dimensions (w x h x d) .151 x 222 x 138 (mm)
.................................................. 5.95 x 8.74 x 5.43 (inch)
GENERAL INFORMATION
AC Power ...................................................120 V / 60 Hz
Dimensions (w x h x d)156 x 222 x 215.5 (mm)
.................................................. 6.14 x 8.74 x 8.48 (inch)
Weight (with/without speakers) ..................................
...............................................................approx. 4.5 / 2.3 kg
.................................................. approx. 9.9 / 5.07 pound
Standby power consumption.......................... < 3 W
Subject to modification
