HOW TO USE FIRST TIME SETUP
F
irst Time Setup automati-
cally takes care of some
basic TV control settings for
you. Follow the steps in this
section to quickly add area
channel numbers into the
TV's memory, and set the TV
for your connected signal
(Antenna or Cable.) You can
also set the TV's Guide Plus+
system feature (if desired).
AUTOMATIC SETTINGS
SETUP
Press the MENU
SELECT button on the
remote or TV.
An on-screen list of TV fea-
tures shows on the "MAIN
MENU".
Note: You may also press the
center Menu ring button area
on the remote to select the
TV’s Main Menu.
2
• Press the STATUS/EXIT but-
ton on the remote or TV to
stop the SETUP at any time.
• Remember, SETUP is a first -use, one-
time operation and will not have to be
repeated (only the clock settings can be
lost).
• Even if there is no Antenna or Cable
signal connected to the ANT(enna) B
input (located on the rear of the TV), 1st
Time Setup will still attempt to add
channels into memory for that source.
In such cases, a channel search in the
Antenna Mode will be completed, and
“0 channels saved in memory” will be
displayed on-screen.
SMART HELP
Note: The Guide Plus+™ system is
an electronic program service avail-
able with your set to show you cur-
rent and future TV listings; program
content descriptions, and other pro-
gramming information. Your TV may display a Guide Plus+ sys-
tem demonstration mode when first turned on for normal opera-
tion and use. Pressing the TV’s control panel or remote control
buttons will enable you to bypass the demonstration and continue
with normal TV program viewing.
Remove the Guide Plus+ Demo Mode Pin (tag label attached to
the “G-LINK” connection plug at the rear of TV) when setting up
the Guide Plus+ system for use (and to completely disable the
automatic demo). Follow the instructions contained in your sepa-
rate Guide Plus+ information manual for feature installation and
other operation details.
Note: Convergence
(or lining up of red
and blue light paths
on the TV screen)
has been preset at
the factory for your conve-
nience and should not need
any further adjustments.
However, Convergence con-
trols are provided (in both the
First Time Setup and Picture
Menu areas) in case the picture on your TV shows color fringing.
Color fringing is when colors “bleed” or appear around the edges
of onscreen images and objects. Please refer to the TV’s Picture
Menu Convergence control page section for further details.
