Philips indoor luminaires4.6
Savio FFS/TFS764
Free oor-standing luminaires
Savio
Type FFS764 (standard, PL-L-lamp version)
TFS764 (standard, TL5-lamp version)
TFS772 (Dynamic lighting, TL5-lamp version)
Light source Compact uorescent:
3 x MASTER PL-L 4 Pin / 2G11 / 55, 80 W
Fluorescent:
3 x or 4 x MASTER TL5 / G5 / 24 W
Lamp included Yes (lamp color 830 or 840) (standard version)
Yes (lamp color 827 and 865) (Dynamic Lighting
version)
Light distribution Direct / Indirect (D/I)
Gear Electronic, 220 - 240 V / 50 - 60 Hz:
High Frequency Regulator, touch-switch, DALI
interface (HFD-T)
Optical cover Acrylate micro lens optic (AC-MLO)
Polycarbonate micro lens optic (PC-MLO)
Option Lighting controls:
Color Variation Controller (CVC)
ActiLume multi controller (ACL)
Euro fuse (FU) included
Material Housing: post-lacquered aluminum, pole and foot
in silver grey
Optical cover: AC-MLO: PMMA, PC-MLO:
polycarbonate
Remarks Delivered as complete luminaire with lamps and
plug cable
TFS772 delivered as KIT with remote controll
Main applications Ofce
Where relevant, for detailed descriptions of Lighting Controls we refer you to chapter 11, and descriptions for e.g. optics/optical covers, lamps data, photometrical diagrams, etc. to the respective sections in chapter 12.
Savio FFS/TFS764/TFS772
Savio FFS/TFS764/TFS772 free-standing
luminaire with PMMA or polycarbonate
micro-lens optic (AC-MLO, PC-MLO),
and Dynamic Lighting option (TFS772
only)
Preferred selection
Product ID Weight
(kg)
European Order
Code (EOC)
FFS764 3xPL-L55W/840 HFD-T AC-MLO 18.10 561296 00
FFS764 3xPL-L80W/840 HFD-T AC-MLO 18.10 561302 00
TFS764 4xTL5-24W/840 HFD-T AC-MLO 17.85 561319 00
FFS764 3xPL-L55W/840 HFD-T AC-MLO ACL 18.15 561326 00
TFS772 3xTL5-24W/827/865 HFD AC-MLO CVC 18.30 561456 00
Please contact your local Philips representative for additional congurations
