SETUPS
HOME “Settings” “Advanced Setup” “Parental”
HOME “Settings”
“Advanced
Setup”
“Audio”
“Analog
Audio”
“Speaker
Setup”
Set the speaker configuration to suite the size/number of
your speakers.
1) Highlight the speaker you want to set in the
illustration on the right.
Speaker Distance
Speaker Setup
Speaker Level
If you press [Red], each speaker outputs the test tone
for 2 seconds in rotation.
You can move among the speakers as illustrated below:
2) Press [OK] repeatedly to change the setting.
Setting
Suitable for
Front
(L/R)
Surround
(L/R)
C e n t e r
sub
woofer
L
A
R
G
E
Large
speakers with
the capacity
for powerful
low frequency
sound.
S
M
A
L
L
Small
speakers
which do not
bare the
powerful low
frequency
sound.*
O
N
When
subwoofer
speaker is
connected.
O
F
F
No speakers.
With regard to the low frequency sound which is less than 100Hz, the
sound will be output from the Subwoofer.
•
*
: [ K ]
: [ L ]
: [ { ]
: [ B ]
• For subwoofer, only on/off is available. (You cannot
change the size of the subwoofer.)
• When the front speakers are set to “small”, subwoofer
setting remains “on” and cannot be changed.
• When subwoofer is set to “off”, the front speaker setting
remains “large” and cannot be changed.
Some BD-video or DVD-video feature a parental lock level.
Playback will stop if the ratings exceed the levels you set,
it will require you to enter a password before the disc will
playback. This feature prevents your children from
viewing inappropriate material.
1) With “Parental” selected in the “Advanced Setup”
menu, press [OK].
Language
Rating level
Audio
Video Output
New PIN
Parental
Others
2) If a PIN code has not been set yet, proceed to step 2-a.
If a PIN code has already been set, proceed to step 2-b.
If you want to change the PIN code, proceed to step 2-c.
If you forget the PIN code, proceed to step 2-d.
2-a) Enter 4 digit PIN code using [the Number buttons],
then press [OK].
Enter new PIN
• “4737” cannot be used.
• Press [Red] to return to the menu screen.
2-b) Enter 4 digit PIN code using [the Number buttons].
Enter your PIN
2-c) Follow step 2-b. Then enter the new PIN code. Press
[OK] when finish entering.
2-d) Enter “4737”, then press [OK]. Current PIN code is
now cleared. Follow step 1. and step 2-a. to create
a new PIN code.
Parental
Speaker Setup
Center
Front (L) Front (R)
Subwoofer
Surround (L)
Surround (R)
