C3412M (9/06) 39
ZOOM LIMIT
Zoom limit allows the user to define a limitation on the amount of telephoto zoom. The settings
vary depending on camera model.
16X (Models DD4TC16 and DD4TC16-X)
The default setting is 32X. Cameras with 128X zoom (16X optical zoom and 8X digital zoom) can
be set for 16X, 32X, 64X, or 128X.
22X (Models DD4M22, DD4M22-X, DD4C22, and DD4C22-X)
The default setting is 32X. Cameras with 264X zoom (22X optical zoom and 12X digital zoom) can
be set for 22X, 32X, 88X, 176X, 220X, or 264X.
23X (Models DD4CBW23 and DD4CBW23-X)
The default setting is 32X. Cameras with 276X zoom (23X optical zoom and 12X digital zoom) can
be set for 23X, 32X, 92X, 184X, 230X, 276X.
35X (Models DD4CBW35 and DD4CBW35-X)
The default setting is 70X. Cameras with 420X zoom (35X optical zoom and 12X digital zoom) can
be set for 35X, 70X, 140X, 280X, 350X, or 420X.
EXIT
SPECTRA IV
LANGUAGE
<SYSTEM INFORMATION>
<DISPLAY SETUP>
<DOME SETTINGS>
ACK ALERT*
RESET CAMERA
CYCLE CAMERA POWER
REBOOT SYSTEM
BACK
EXIT
<CAMERA>
<MOTION>
<POWER UP>
<LINE SYNC>
<PRESETS>
<PATTERNS>
<ZONES>
<WINDOW BLANKING>
<ALARMS>
<AUX>
<TITLE TEXT>
<ALERT>*
<CLEAR>
<PASSWORD>
<CLOCK>
<EVENT>
DOME SETTINGS
BACK
EXIT
TYPE OF LIGHTING
AUTO FOCUS
ZOOM LIMIT
ZOOM SPEED
LOW LIGHT LIMIT
IR CUT FILTER
AUTO IR LEVEL
<ADVANCED SETTINGS>
CAMERA
*This setting applies only to Pressurized Spectra IV dome systems.
