Trouble Shooting (Continued)
The Grille is not Heating (Indicator Light Is
On) (Continued)
• If the thermostat is properly set, and working,
and the selector switch is set for top
and bottom platen heating, and both platens are still not getting hot, have a qualified
electrician check the selector switch, both heating elements as well as their
connective wiring.
• If the thermostat is properly set, and working,
and the selector switch is set for top
and bottom platen heating, and only one of the platens is getting hot, have a
qualified electrician check the selector switch, the heating element which is not
getting hot as well as their connective wiring.
Product is Either Burning or Under Cooking
• The thermostat, (temperature selection knob), may be improperly set, increase or
decrease the setting as required.
• Have a service technician use a temperature sensing device to compare the actual
temperature of the platens with the set temperature indicated on the front control
panel. Both platens should be heated with the top platen in the closed position.
Please realize that the numbers on the control panel are only approximate and that
the actual temperature may very +/- 25º F.
The Top Platen Falls If not Held
• Using a screw driver, (through the access hole in the spring cover), increase the
amount of drag on the top platen hinge pin. Rotating the screw in a clockwise
direction will increase the drag.
• The assist spring as failed. Have a service technician replace it.
The Optional Digital Timer Does Not Turn On (The Rest of the Unit is Working)
• Have a qualified electrician check the transformer, the timer and its connective
wiring.
The Optional 4 Menu Digital Time Does Not Turn On (The Rest of the Unit is Working)
• Have a qualified electrician check the timer and its connective wiring.
