0502S20003 2-2
Space Requirements, (Shown with Standard Options):
Model 502 & 502-N (All Dimensions are Approximate)
Standard Electrical Options: (Others consult factory).
WARNING
THIS UNIT MUST BE CONNECTED TO A DEDICATED
ELECTRICAL CIRCUIT
COMPATIBLE WITH THE LOAD THE GRILLE WILL PLACE ON IT.
Model 501/501-N Single Upper Platen Panini Grille
1 phase, 60 hz, 115VAC, 18 Amps, 1800 Watts.
1 phase, 60 hz, 208/240VAC, 10 Amps, 1685/2250 Watts.
1 phase, 50 hz, 220VAC, 9 Amps, 1890 Watts.
Model 502/502-N Double Upper Platen Panini Grille
1 phase, 60 hz, 208/240VAC, 20 Amps, 3375/4500 Watts.
1 phase, 50 hz, 220VAC, 18 Amps, 3775 Watts
