At a glance
Instrument cluster
Item Page
8 Multifunction display with:
ț Trip odometer 157
ț Main odometer 159
9 Tachometer with:
< Seat belt telltale 79,
426
1 Supplemental
Restraint System
(SRS) indicator lamp
72,
430
? Engine malfunction in-
dicator lamp,
USA only
423
± Engine malfunction in-
dicator lamp,
Canada only
423
Item Page
A High beam headlamp
indicator
150
q Preglow indicator
lamp
1
a Fuel gauge with:
Fuel tank reserve warning
lamp
430
4 Fuel filler flap indica-
tor: The fuel filler flap
is located on the rear
right-hand side
360
1
Vehicles with diesel engine only.
Item Page
b Multifunction display with:
ț Outside temperature
display or digital speed-
ometer (depending on
selected setting in the
control system)
159,
180
ț Transmission position
indicator
201
ț Gear range indicator 205
ț Selected program mode
indicator
206
ț Distance warning function
indicator*
284
ț Rear window wiper
indicator
62
