Feature Highlights

13 14

BLIND SPOT MONITORING (BSM) SYSTEM

The Blind Spot Monitoring (BSM) system is designed to assist the driver

by monitoring the blind spots to the rear of the vehicle on both sides.

 • Ifyourvehiclespeedis20mph(32km/h)ormore,theBSMwillwarn

youofvehiclesinthedetectionareabyilluminatingtheBSMwarning

lightslocatedontheleftandrightdoormirrors.

 • IfyouoperateaturnsignalinthedirectionofanilluminatedBSM

warninglight,thesystemwillalsowarnyouwithabeepingsoundand

warninglightash.

 • BSMsensorsarelocatedundertheleftandrightrearbumperareas.

TheBSMsystemmaynotoperateproperlyiftherearbumpergetstoo

dirty,sokeeptherearbumperareaclean.

PleaserefertoyourOwner’sManualforcompletedetails.

Your Vehicle

Detection Areas

NOTE: Do not rely completely on the BSM system and be sure to look over

your shoulder before changing lanes:

•

TheBSMsystemcanassistthedriverinconrmingthesafetyofthesurroundings,

 butisnotacompletesubstitute.

• Thedriverisresponsibleforensuringsafelanechangesandothermaneuvers.

• Alwayspayattentiontothedirectioninwhichthevehicleistravelingandthe

 vehicle’ssurroundings.

• TheBSMsystemdoesnotoperatewhenthevehiclespeedislowerthanabout

 20mph(32km/h).

Turning BSM System Off

TomanuallyturntheBSMsystemoff,pushtheBSMOFFswitchonthedash.

TheBSMOFFindicatorwillilluminateintheinstrumentclusterwhentheBSM

systemisoff.TheBSMsystemwillautomaticallyturnonthenexttimethe

vehicleisstarted.

Outside Temperature/

Interior Set

Temperature

Climate

Control

Audio

INFORMATION DISPLAY

Temperature

Display

(Passenger)

Clock

NOTE:ForstandardaudioandNavionly.MidAudioshowsTripcomputerhere.

PORTABLE

AUDIO

PLAYER

INTEGRATION

USING

THE

AUX

JACK

YourvehicleisequippedwithanAUXorauxiliary

jackthatwillallowyoutoplayyourportableaudio

playerthroughthevehicle’saudiosystem.Learn

thesystemwhenparkedanddonotletitdistract

youwhiledriving.

NOTE:

AvailableatyourMazdadealeristheGenuineMazdaAccessory3.5mm

audiocablewhichcanbeusedtoconnectyourportableaudioplayerintothe

auxjack.

1 LocatetheAUXjackinsidethecenterconsole.

2 Plug3.5mmaudiocableintotheportableaudioplayerandintothe

AUXjack.Turnportableaudioplayeron.

3 Turnthevehicleaudiosystemon.

4 • Without Navigation System:PushAUXbuttononaudiosystem

ORpushMODEbuttononsteeringwheelcontrolsuntil“AUX”

   isdisplayed.

  • With Navigation System:PushSOURCEbuttononaudio

   system,thenpushAUX1onscreenORpushMODEbuttonon

   steeringwheelcontrolsuntil“AUX1”isdisplayed.

5 Usetheportableaudioplayercontrolstoplaymusic.

IMPORTANT:

Setthevolumelevelonyourportableaudioplayertothehighest

levelbeforedistortionstarts,thenadjustthevolumeontheaudiosystem.

www.MazdaUSA.com
