Owner’s Manual 17
Operation
Picture Menu Options
Picture Menu Options
- XD is LG Electronic’s unique picture improving technology to display a real HD
source through an advanced digital signal processing algorithm.
- When selecting APC options (Clear, Optimum and Soft), XD is automatically
change to On.
1. Press the MENU button and then use
DD / EE
button to select the PICTURE menu.
2. Press the
GG button and then use
DD / EE
button to select XD.
3. Press the GG button and then use
DD / EE
button to set On or Off.
4. Press the OK button to save.
XD
XD
1. Press the APC button repeatedly to select the picture appearance setup option as shown below.
APC (Auto Picture Control)
APC (Auto Picture Control)
• You can also adjust APC in the PICTURE menu.
• Daylight, Optimum and Night time settings are preset for good picture quality at the factory and cannot be
changed.
Daylight
Optimum Night time Off
- APC adjusts the Monitor to the best picture appearance.
- If adjusting picture options (contrast, brightness, color, sharpness, or tint) manually, APC automatically
changes to Off.
Auto Color Temperature Control
- To initialize values (reset to default settings), select the Normal option.
1. Press the MENU button and then use
DD / EE
button to select the PICTURE menu.
2. Press the GG button and then use
DD / EE
button to select ACC .
3. Press the GG button and then use
DD / EE
button to select either: Cool (Preset),
Normal (Default), or Warm (Preset).
4. Press the OK button to save.
Color
Color
T
T
emperature Control
emperature Control
Manual Color Temperature Control (
ACC set to Off option)
- You can adjust red, green, or blue to any color temperature you prefer.
1. Press the MENU button and then use
DD / EE
button to select the PICTURE menu.
2. Press the GG button and then use
DD / EE
button to select ACC .
3. Press the GG button and then use
DD / EE
button to select Off.
4. Press the
GG button and then use
DD / EE
button to select Red, Green or Blue.
5. Use the
FF / GG button to make appropriate adjustments.
• The adjustment range of Red, Green,
and
Blue is -30 ~ +30.
6. Press the OK button to save.
Prev.
APC
ACC GG
Fleshtone
Contrast 100
Brightness 55
Color 55
Sharpness 60
Tint 0
Menu
Cool
Normal
Warm
Off
Red 0
Green 0
Blue 0
Prev.
APC
GG
ACC
Fleshtone
Contrast 100
Brightness 55
Color 55
Sharpness 60
Tint 0
Menu
On
Off
