23
ENGLISH
Preferred Setting Mode (PSM) items
The PSM items are grouped into five categories—“Disp (display),” “Clock,” “Tuner,” “Color,” and “Audio.”
To select a desired item, first select the category where the desired item is listed.
Indications
All Time
Off
Off
Once
Auto
Interval
Disp (display)
Clock
Color
Intermediate frequency
filter
On
Auto
Off
Tuner
Audio
*
3
Displayed only when “Mode” is set to “User.”
*
4
Displayed only when one of the following sources is
selected – FM, AM and CD.
*
1
Displayed only when “Mode” is set to “Source.”
*
2
What appears actually here—source name—varies
according to the “Source” setting.
See
page
Factory-preset
settings
To set changing source animation on the
display—SRC Anime
When changing the source, the display shows the
changing source animation. If you do not want this
animation you can turn it off.
• On: Changing source animation appears
just after you change the source.
• Off: Cancels the changing source
animation. (Simple source animation
is used.)
To set movie demo—MovieDemo
When shipped from the factory, the movie demo
has been activated (“All Time” is selected).
• All Time: If no operatoin is done for about 20
seconds, movie demo
automatically starts.
• Interval: If no operatoin is done for about 20
seconds, movie demo and plaback
source indication alternately appears
on the display.
• Off: Cancels the movie demo.
Selectable values
Positive
Negative
Auto
MovieDemo Movie demo All Time 8, 23
SRC Anime Changing source On Off On 23
animation
Scroll Scroll mode Once 24
Dimmer Dimmer mode Auto 24
Contrast Contrast Contrast 1 — Contrast 10 5 24
LCD Type Display type Positive 24
Font Type Font type 1 2 1 24
Clock Hr Hour adjustment 1 —12 1 (1:00) 22
Clock Min Minute adjustment 00 —59 00 (1:00) 22
IF Filter Auto Wide Auto 24
Mode Color mode Source User Source 25
Source*
1
Source color selection See page 25 for details All Source 25
All Source*
2
(Selected source) See page 25 for details Every 25
User*
3
User color selection Day Night Day 26
Red*
3
Red 0 — +11 Day: +7 / Night:+5 26
Green*
3
Green 0 — +11 Day: +7 / Night:+5 26
Blue*
3
Blue 0 — +11 Day: +7 / Night:+5 26
Beep Key-touch tone On Off On 24
Ext Input*
4
External component Changer Line In Changer 24
