Once the camcorder is set, the camcorder operator
can become part of the scene in a more natural way,
adding the final touch to a memorable picture.
1 Set the Power Switch to “M” while pressing down
the Lock Button located on the switch.
2 Open the LCD monitor fully, or pull out the
viewfinder fully.
3 Set “SELF TIMER” to
“ON ”. (੬ pg. 38)
● You can tilt the LCD
monitor upward to
180° so that it faces
forward and view
yourself while self-
recording with the
viewfinder pushed
back.
4 To engage the Self-
Timer for video
recording, press the
Recording Start/Stop
Button.
● After 15 seconds, the
beep sounds and
video recording
starts.
5 To stop Self-Timer recording, press the Recording
Start/Stop Button again.
● The camcorder re-enters Record-Standby
mode.
OR
5 Press SNAPSHOT.
● After 15 seconds, the beep sounds and
snapshot recording starts. After that, the
camcorder re-enters Record-Standby mode.
6 To end Self-Timer recording, select “OFF” in
step 3.
NOTE:
If “BEEP” and “TALLY”are set to “OFF” (੬ pg. 47),
the beep does not sound and the tally lamp does not
light.
Self-Timer
Power Switch
Lock Button
VIDEO/MEMORY
Switch
Recording Start/
Stop Button
MENU Button
SET/SELECT Button
+, – Button
SELF–TIMER –
ON
OFF
Self-Timer indication
When the Recording Start/Stop Button or SNAPSHOT
is pressed, the tally lamp changes as shown:
Begins blinking
(Self-Timer starts)
Blinks quickly
(Self-Timer shooting
starts soon)
Turns off
(Self-Timer snapshot recording starts)
Stops blinking and stays on
(Self-Timer video recording starts)
After approx. 15 sec.
