Fitted with the KA-M790G and the KA-790G, the GY-HM790U can be used
to construct an economical HD or SD studio system for stunning images.
■
Both HD or SD component and SDI video are supported, giving user
flexibility to use a component switcher or SDI switcher.
■
Lossless SDI output from GY-HM790U can be delivered to RM-HP790DU
via multicore/BNC hybrid cable
■
Reliable tripod-mounted studio operation with pedestal and teleprompter.
■
When replacing a GY-DV550U or GY-HD250U based studio system,
the original 26-pin control cable can continue to be used.
■
When connecting KA-M790G to a RM-HP250AU unit, users' existing 26-pin
Sony cable can be used.
■
When needed, the GY-HM790U can be used as an ENG camera by
releasing the camera from KA-790G.
■
Fitted with the ProHD fiber studio interface unit and the KA-790G,
the GY-HM790U can be converted into an economical HD or SD studio
system.
■
Both HD or SD component and SDI video are supported, providing
flexibility to use a component switcher or SDI switcher.
■
Optical fiber system allows longer cable distance operation with optional
Power Wafer.
■
When needed, the GY-HM790U can be used for ENG by releasing the
camera from the KA-790G studio sled support.
over All of Your Workflow Possibilities
HD/SD Multicore Studio System
HD/SD Fiber Studio System
6
Photo courtesy of
Waterman Broadcasting Corp.
Photo courtesy of
Ole Miss Athletics & Media Support Group
