EN 49
1. POWER button
• Turns the device on and off.
• If power is not supplied to the
camcorder beforehand, you can not
turn the camcorder on and off by
clicking this button.
• Some camcorders cannot be turned on
and off by clicking this button.
2. COUNTER system
3. Tape counter display
• Displays actual tape position.
ex.
00: 01: 45: 10F
(Hours : Minutes : Seconds : Frames)
4. ID number
• Displays the selected device's ID
number.
5. FILE name
• Displays file name after saving the
program under a new name.
ex. travel
6. MEMO
• If you wish to add some comment to
the file, you can input it.
ex. Europe Tour
7. IN/OUT point display
• You can set up to 99 in/out points per
file.
8. SCENE button
• Plays back only one programmed scene
so that you can preview it.
• Operates only the camcorder.
9. START button
• Starts editing. Scenes are recorded in
scene's numerical order. After starting
editing, this button changes to STOP
button.
10. ELAPSED TIME
• Displays the total elapsed time of all
the programmed scenes.
11. Camcorder's operation buttons
•Operate the camcorder.
Stop button
REW/REW Search button
Play button
FF/FF Search button
Pause button
Reverse Slow button
Forward Slow button
• To start Reverse/Forward Slow-motion
Search, first click the Pause button and
then the Reverse/Forward Slow button.
•Functions your camcorder does not
have cannot be performed by the above
buttons.
•Click "Window" — "VCR Control" on
menubar to call up the "VCR Control"
window. You can control the video
source unit from this window.
12. IN/OUT point button
• Registers the cut-in and -out points of
the scene you want to dub.
13. P.AE/Effect buttons
• Set one of the 5 P.AE/Effects per
programmed scene.
• To cancel the selected effect, press the
EC (Effect Clear) button.
14. Fade/Wipe Effect buttons
• Set one of the 7 Picture Wipes and 10
Fades/Wipes per scene transition.
• To cancel the selected effect, press the
TC (Transition Clear) button.
15. Message display
• Displays the connected device mode,
etc.
To exit from the VIDEO PRODUCER
window, choose "Exit" from "File".
NOTE:
If you need the "JLIP VIDEO PRODUCER
HELP" window, choose "Contents" from
"Help".
