EN69
Controls
1 Dioptre Adjustment Control ................. ੬ pg. 12
2 Lens Cover Open/Close Ring
[LENS COVER] .................................... ੬ pg. 14
3 Video Light Switch
[LIGHT OFF/AUTO/ON]...................... ੬ pg. 26
4 Snapshot Button [SNAPSHOT] ....... ੬ pg. 18, 22
5 •Power Zoom Lever [T/W] .................. ੬ pg. 24
•Speaker Volume Control [VOL.] ........ ੬ pg. 43
6 Picture Stabilizer Button
[P.STABILIZER]..................................... ੬ pg. 25
7 Programme AE Button [P.AE] ................ ੬ pg. 28
8 Fade/Wipe Button [EFFECT] ................. ੬ pg. 27
9 System Select Switch
[D.S.C./VIDEO] ................ ੬ pg. 14, 18, 42, 48
0 •Rewind Button
[
2
, REW/PAGE–] ...................... ੬ pg. 42, 48
•Retake Rewind Button [RETAKE R]..... ੬ pg. 25
•Quick Review Button [ R] ............. ੬ pg. 25
! •Fast-Forward Button
[
3
, FF/PAGE+] .......................... ੬ pg. 42, 48
•Retake Forward Button [RETAKE F] .... ੬ pg. 25
@ Stop Button [5, STOP] ......................... ੬ pg. 42
# Play/Pause Button
[
4
/6, PLAY/PAUSE]............................. ੬ pg. 42
$ •Select Dial [+, –, PUSH] ................ ੬ pg. 9, 32
•Bright Dial [BRIGHT] ........................ ੬ pg. 17
% MENU/DISPLAY Button ................. ੬ pg. 15, 32
^ •Counter Reset/Memory Button
[COUNTER R/M] .............................. ੬ pg. 44
•Recording Mode Button [SP/LP]......... ੬ pg. 10
& EJECT Switch ....................................... ੬ pg. 11
* Recording Start/Stop Button.................. ੬ pg. 14
( Power Switch .................... ੬ pg. 14, 18, 42, 48
) Battery Release Switch
[BATTERY RELEASE] .............................. ੬ pg. 6
q PUSH Button ....................................... ੬ pg. 11
Connectors
w DC IN Jack ............................................ ੬ pg. 7
The connectors e to y are located beneath the
cover.
e Video Output Connector...................... ੬ pg. 46
r Audio Output Connector ..................... ੬ pg. 46
t J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
•Connect the editing cable when performing
Random Assemble Editing (੬ 58 – 61).
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
y Digital Connector ............................... ੬ pg. 49
Indicators
u Tally Lamp ........................................... ੬ pg. 14
i Power Lamp ........................................ ੬ pg. 14
Other Parts
o Battery Pack Mount ............................... ੬ pg. 6
p Viewfinder ........................................... ੬ pg. 12
Q Grip Strap............................................ ੬ pg. 12
W •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor .................................. ੬ pg. 57
E Video Light .......................................... ੬ pg. 26
R Microphone......................................... ੬ pg. 64
T Eyepiece.............................................. ੬ pg. 74
Y Speaker ............................................... ੬ pg. 43
U LCD Monitor ....................................... ੬ pg. 17
I Shoulder Strap Eyelets .......................... ੬ pg. 13
O Clock Battery Slot .................................. ੬ pg. 8
P Tripod Mounting Socket ....................... ੬ pg. 13
