Dubbing From A VCR
[To Use This Camcorder As A Recorder]
1 Make sure all units are turned off, then connect
the camcorder and the VCR as shown in the
illustration. Also refer to pg. 54 and 55.
2 Set “SOUND MODE” to “12 BIT” or “16 BIT” and
“REC MODE” to “SP” or “LP” in the Menu Screen
depending on your preference (੬ pg. 32).
3 Set the camcorder’s Power Switch to “ ” while
pressing down the Lock Button located on the switch.
Turn on the VCR’s power and insert the appropriate
cassettes in the camcorder and the VCR.
4 Set “S/AV INPUT” to “ON” in the Menu Screen to
engage the analogue input mode (੬ pg. 32).
5 Press the Recording Start/Stop Button on the
camcorder to engage the Record-Pause mode.
“
AV. IN
” appears on the screen.
6 Engage the VCR’s Play mode, then engage the
Still Playback mode when you have found a spot just
before the edit-in point.
7 Press the Recording Start/Stop Button on the
camcorder to engage the Record mode. rotates
on the screen. Engage the VCR’s Play mode.
8 To stop dubbing, press the Recording Start/Stop
Button on the camcorder so that stops rotating,
then engage the VCR’s Stop mode.
9 Repeat steps 6 through 8 for additional editing.
10
Set “S/AV INPUT” back to “OFF” in the Menu
Screen to disengage the analogue input mode
(੬ pg. 32).
NOTES:
● It is recommended to use the AC Power Adapter/
Charger as the power supply instead of the battery
pack (
੬ pg. 9).
● Analogue signals can be converted to digital signals
with this procedure.
● It is also possible to dub from another camcorder.
* Connect when an S-Video cable is not used.
** When connecting the cables, open this cover.
Connector
cover**
To
AV
To
S-VIDEO
S-Video
cable
(provided)
Power Switch
TV
Audio/Video cable
[mini-plug to
RCA plug]
(provided)
VCR (Playback deck)
To AUDIO, VIDEO*
and S-VIDEO OUT
connectors
