1 • MENU Wheel [–, +] ................................ ੬ pg. 18
• BRIGHT Wheel [–, +] .............................. ੬ pg. 11
• Speaker Volume Control [VOL.] .............
੬ pg. 11
• TRACKING Wheel [–, +] ........................
੬ pg. 14
2 5-Second Recording Button
[5 SEC. REC]...........................................
੬ pg. 12
3 Power Zoom Lever [T/W]......................... ੬ pg. 13
4 • Manual Focus Button [ FOCUS]........ ੬ pg. 12
• Time Base Corrector Button [TBC] ........ ੬ pg. 14
5 Audio Output Connector [A]..................... ੬ pg. 15
6 Video Output Connector [V] ..................... ੬ pg. 15
7 Battery Release Switch
[BATTERY RELEASE] ...............................
੬ pg. 6
8 DC IN Connector ....................................... ੬ pg. 6
9 Recording Start/Stop Button .....................੬ pg. 11
0 Lock Button...............................................੬ pg. 11
! Power Switch [PLAY, OFF, , ]........... ੬ pg. 11
@ POWER Lamp ........................................... ੬ pg. 6
# Digital Effect Button [DIGIFECT] ............. ੬ pg. 24
$ Programme AE Button [P.AE] .................. ੬ pg. 24
% Play/Pause Button ....................................੬ pg. 11
^ • Retake Forward Button [RETAKE F] ..... ੬ pg. 13
• Fast-Forward Button [F] ..........................
੬ pg. 11
& EJECT Switch ............................................ ੬ pg. 8
* CHARGE Lamp ......................................... ੬ pg. 6
( REFRESH Button ...................................... ੬ pg. 6
) • Fade/Wipe Button [FADE/WIPE] ........... ੬ pg. 23
• Counter Reset/Memory Button
[COUNTER R/M] ...................................
੬ pg. 14
q • Retake Rewind Button [RETAKE R] ...... ੬ pg. 13
• Quick Review Button [
R] ................. ੬ pg. 13
• Rewind Button [R] ...................................੬ pg. 11
w • Stop Button [STOP] ................................ ੬ pg. 11
• Backlight Compensation Button
[BACK LIGHT] .......................................
੬ pg. 12
e Shoulder Strap Eyelets .............................. ੬ pg. 8
r Battery Pack Mount ................................... ੬ pg. 6
t Close Button .............................................. ੬ pg. 8
y Dioptre Adjustment Control ........................ ੬ pg. 8
u Camera Sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
i Grip Strap .................................................. ੬ pg. 8
o Tripod Mounting Socket ............................. ੬ pg. 8
p Tape Remaining Time .............................. ੬ pg. 21
Q Recording Mode Indicator ....................... ੬ pg. 20
W Backlight Compensation Indicator ........... ੬ pg. 12
E • Digital Effect Indicator ............................ ੬ pg. 24
• Programme AE Indicator .......................
੬ pg. 24
• Fade/Wipe-Standby Indicator ................ ੬ pg. 23
R Tape Length Indicator .............................. ੬ pg. 20
T Zoom Indicator Bar .................................. ੬ pg. 13
Zoom Level Indicator
Approximate Zoom Ratio
Y Recording Indicator ..................................੬ pg. 11
U Digital Effect Indicator .............................. ੬ pg. 24
I Programme AE Indicator ......................... ੬ pg. 24
O Fade/Wipe-Standby Indicator .................. ੬ pg. 23
P Picture Stabiliser Indicator ....................... ੬ pg. 18
a • Interval Time/Recording Time Indicator .... ੬ pg. 21
• 5 Sec. Rec Mode Indicator .................... ੬ pg. 12
s Bright Level Indicator ..........................੬ pg. 11, 22
d Instant Title Display ................................. ੬ pg. 19
f Date/Time Display ................................... ੬ pg. 20
g Focus Indicator ........................................ ੬ pg. 12
h Exposure Control Level Counter ............. ੬ pg. 18
j White Balance Mode Indicator................. ੬ pg. 19
k Record-Standby Mode Indicator ...............੬ pg. 11
l : Cassette Indicator ............................. ੬ pg. 8
; TBC Indicator........................................... ੬ pg. 14
A Tape Counter ........................................... ੬ pg. 14
S Recording Mode Indicator (SP/EP) ......... ੬ pg. 20
D Tape Running Indicator
4
: Playback
3
: Fast-Forward/Shuttle Search
2
: Rewind/Shuttle Search
6 : Pause
F Tracking Indicator .................................... ੬ pg. 14
G • BRIGHT: Bright Level Indicator............... ੬ pg. 11
• VOLUME: Speaker Volume Indicator ......
੬ pg. 11
