23
2. CONTROLS, INDICATORS AND CONNECTORS
Setting Condition Contents of Indications
When the gain value is changed GAIN –3 dB, 0dB, 3dB, 6 dB, 9 dB, 12 dB, 15 dB, 18 dB.
When gain is ALC GAIN ALC
When the LOLUX mode is ON/OFF LOLUX ON, LOLUX OFF
When the AUTO KNEE is ON/OFF AUTO KNEE ON, AUTO KNEE OFF
When the FULL AUTO is ON/OFF FULL AUTO ON, FULL AUTO OFF
When the ZEBRA is ON/OFF ZEBRA ON, ZEBRA OFF
When the shutter speed is changed SHUTTER 1/7.5, 1/15, 1/30, 1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000,
1/10000
When the variable shutter speed is changed V. SHUTTER 1/60.1 to 1/2084.6
When the shutter is OFF SHUTTER OFF
(Shutter speed: 1/60)
When the white balance value is changed (Example) WHITE BAL A <3200K>
Numeric value : Any of 2300, 2500, 2800, 3000, 3200, 3400, 3700, 4300, 5200,
5600, 6500, 8000
9 Event Indication
When the Gain or Shutter Speed is changed manually, the setting condition is displayed for about 3 seconds at the time the
change is made.
●
Status 1
In addition to the information on the Status 0 screen, this screen displays the following items.
No. Item Contents
0 Voltage indication (Example) 12.2V: Indicates battery voltage in 0.1V steps.
or (Example)
100%: Remaining battery is shown in percentage [%].
Battery indication (Example)
60min: Remaining battery is shown in minutes [min].
Select the display method with the BATTERY INFO item on the LCD/VF
(2/2) menu. ☞ See page 82
A Time Code (TC)/User’s Bits (UB) indication Indicates the time code (h:m:s:frame) or user’s bits data.
(Example) Time code TC 00 : 00 : 00 : 00
User’s bits UB FF EE DD 20
Whether or not to display this item is set with the TC/UB item on the LCD/
VF (2/2) menu screen. Whether the time code or user’s bits should be
shown is selected with the COUNTER switch inside the side cover.
B Remaining tape indication Remaining tape indication (displayed in 1-minute steps)
This indicator blinks when remaining tape time is equivalent to less than 3
minutes.
Whether or not to display this item is set with the TAPE REMAIN item on
the LCD/VF (2/2) menu screen.
* When inserting a brand-new tape, the remaining tape time is not indicated.
When the tape has been run, the indication will appear.
* The remaining tape indication is to be regarded only as a guide.
* When the unit is used at low temperatures, it may take a while before the
indication of the remaining tape time appears.
C Audio sampling frequency indication 32 K:Indicated when the AUDIO MODE item on the AUDIO/VIDEO menu
screen is set to 32 K. (Audio is recorded with 12-bit, 32 kHz
sampling.)
48 K : Indicated when the AUDIO MODE item on the AUDIO/VIDEO menu
screen is set to 48 K. (Audio is recorded with 16-bit, 48 kHz
sampling.)
D Audio level meter indication Displays the CH-1, CH-2 audio level meters.
Whether or not to display this item is set with the AUDIO DISPLAY item on
the LCD/VF (2/2) menu.
E Standard audio level indication The level at which audio is recorded on the tape is indicated by “■”.
–20dB, –12dB
☞ See “AUDIO REF. LEVEL” on page 80.
–20dB –12dB
❘❘
CH 1 ■ ■ ■ ■ ■
CH 1 ■ ■ ■■■ – – – +
CH 2 ■ ■ ■■■ – – – +
Non-drop frame: Colon (:)
Drop frame: Dot (.)
E-23
2. CONTROLS, INDICATORS AND CONNECTORS
●
Status 1
In addition to the information on the Status 0 screen, this screen displays the following items.
No. Item Contents
0 Voltage indication (Example) 12.2V : Indicates remaining battery level in 0.1V steps.
or (Example)
100% : Remaining battery is shown in percentage [%].
Battery indication (Example)
60min : Remaining battery is shown in minutes [min].
Select the display method with the BATTERY INFO item on the LCD/VF
(2/2) menu. ☞ See page 82.
A Time Code (TC)/User’s Bits (UB) indication Indicates the time code (h:m:s:frame) or user’s bits data.
(Example) Time code TC 00 : 00 : 00 : 00
User’s bits UB FF EE DD 20
Whether or not to display this item is set with the TC/UB item on the LCD/
VF (2/2) menu screen. Whether the time code or user’s bits should be shown
is selected with the COUNTER switch inside the side cover.
B Remaining tape indication Remaining tape indication (displayed in 1-minute steps)
This indicator blinks when remaining tape time is equivalent to less than 3
minutes.
Whether or not to display this item is set with the TAPE REMAIN item on
the LCD/VF (2/2) menu screen.
*When inserting a brand-new tape, the remaining tape time is not indicated.
When the tape has been run, the indication will appear.
* The remaining tape indication is to be regarded only as a guide.
* When the unit is used at low temperatures, it may take a while before the
indication of the remaining tape time appears.
C Audio sampling frequency indication 32 K : Indicated when the AUDIO MODE item on the AUDIO menu screen
is set to 32 K. (Audio is recorded with 12-bit, 32 kHz sampling.)
48 K : Indicated when the AUDIO MODE item on the AUDIO menu screen
is set to 48 K. (Audio is recorded with 16-bit, 48 kHz sampling.)
D Audio level meter indication Displays the CH-1, CH-2 audio level meters.
Whether or not to display this item is set with the AUDIO item on the LCD/
VF (2/2) menu.
E Standard audio level indication The level at which audio is recorded on the tape is indicated by “■”.
–20dB, –12dB
☞ See “AUDIO REF. LEVEL” on page 80.
Setting Condition Contents of Indications
When the gain value is changed GAIN –3 dB, 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, 18 dB.
When gain is ALC GAIN ALC
When the LOLUX mode is ON/OFF LOLUX ON, LOLUX OFF
When the AUTO KNEE is ON/OFF AUTO KNEE ON, AUTO KNEE OFF
When the FULL AUTO is ON/OFF FULL AUTO ON, FULL AUTO OFF
When the ZEBRA is ON/OFF ZEBRA ON, ZEBRA OFF
When the shutter speed is changed SHUTTER 1/6.25, 1/12.5, 1/25, 1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000
When the variable shutter speed is changed V. SHUTTER 1/50.1 to 1/2067.8
When the shutter is OFF (Shutter speed: 1/50) SHUTTER OFF
When the white balance value is changed (Example) WHITE BAL A <3200K>
Numeric value : Any of 2300, 2500, 2800, 3000, 3200, 3400, 3700, 4300,
5200, 5600, 6500, 8000
9 Event Indication
When the Gain or Shutter Speed is changed manually, the setting condition is displayed for about 3 seconds at the time the
change is made.
–20dB –12dB
❘❘
CH 1 ■ ■ ■ ■ ■
CH 1 ■ ■ ■■■ – – – +
CH 2 ■ ■ ■■■ – – – +
E
U
