3
Advantage Features Benefits
High Availability • Fully redundant hardware
(Cooling, power supplies, Routing Engines, Switch
Control Boards)
• Modular Operating System
• Separate Data and Control Planes
• Graceful Restart
• Non-stop Routing
• MPLS FRR
• VPLS Multi-homing
• The MX960 design provides the highest level of redundancy
and resiliency to ensure that critical services and
customers stay connected.
• Enables service providers to maximize revenues and ensure
customer satisfaction.
High Performance Powered by Juniper’s next-generation I-chip ASIC, the MX960
features include:
• Enhanced QoS capabilities
• Additional packet processing exibility
• Scaling enhancements including route lookup, next hop, IFL
scaling, and interface accounting
• Additional microcode capacity that provides headroom for
the next three-to-ve years of JUNOS features
• Enhanced multicast performance
Industry leading performance enables the MX960 to satisfy
critical applications at the edge, including voice, video and
data.
Service Flexibility Simultaneous support for Layer 2 and Layer 3 Ethernet
services: VPLS, RFC 2547bis IP/MPLS VPNs, Triple Play
services
Providing enterprise and residential services from a common
platform increases service breadth and optimizes OPEX and
CAPEX.
MX960 Specifications
Specification Description
Physical Dimensions (W x H x D) 17.5 x 27.8 x 23.5 in
44.5 x 70.5 x 59.7 cm
Weight (lbs/kgs) Chassis: 138 lbs / 62.7 kgs
Fully Congured: 334 lbs / 151.8 kgs
Power (AC, DC) DC power: -48V, -60V DC
AC power: 200 to 240V AC
Operating Temperature 32° to 104° F / 0° to 40° C
Humidity 5% to 90% noncondensing humidity
Approvals
Safety Approvals
• CAN/CSA-22.2 No. 60950-00/UL 1950 Third Edition, Safety of Information Technology
Equipment
• EN 60825-1 Safety of Laser Products - Part 1: Equipment Classication, Requirements and
User’s Guide
• EN 60950 Safety of Information Technology Equipment
Immunity
• EN 61000-3-2 Power Line Harmonics
• EN 61000-4-2 ESD
• EN 61000-4-3 Radiated Immunity
• EN 61000-4-4 EFT
• EN 61000-4-5 Surge
• EN 61000-4-6 Low Frequency Common Immunity
• EN 1000-4-11 Voltage Dips and Sags
EMC
• AS/NZS 3548 Class A (Australia/New Zealand)
• BSMI Class A (Taiwan)
• EN 55022 Class A Emissions (Europe)
• FCC Part 15 Class A (USA)
• VCCI Class A (Japan)
NEBS
• GR-63-Core: NEBS, Physical Protection
• GR-1089-Core: EMC and Electrical Safety for Network Telecommunications Equipment
ETSI
• ETS-300386-2 Telecommunication Network Equipment Electromagnetic Compatibility
Requirements
Management
Element Management: J-Web Graphical User Interface
Policy Management: SDX-300 Service Deployment System, JUNOScope IP Service Manager
Third Party Management Applications: Dorado, InfoVista, Micromuse, WANDL
SNMP: SNMP v2/v3 bilingual agent support
