8
ENGINE TECHNICAL DATA N67 ENT M45
The technical code and serial number are indicated on a plate, which is
located on different parts of the engine, according to the model: flywheel
casing, tappet cover, coolant tank.
(*)Net power to the flywheel in compliance with ISO 3046-1. Test
conditions: T 25 °C; atmospheric pressure 100 kPa; relative
humidity 30%.
Code N67 ENT M45
Engine family F4
Cycle 4-stroke diesel
Number and arrangement
of cylinders 6, in line
Bore x stroke 102 x 120 mm
Total displacement 5.900 cm
3
Air system Supercharged aftercooled
(TCA or TAA)
Injection type Direct/Common rail
electronically managed
Engine direction of rotation Anticlockwise
(seen from flywheel side)
Dry weight 595 kg
Electrical system 12 V (24 V on request)
Accumulator/s
- capacity 180 Ah or above
- discharge current 800 A or above
Available settings (*) N67 ENT M45
A1 331 kW (450 CV) @ 3000 rpm
A2 309 kW (420 CV) @ 3000 rpm
B
272
kW (370 CV) @ 3000 rpm
C 258 kW (350 CV) @ 3000 rpm
WARNING
Any alteration of the above mentioned characteristics, in particular
modification of the data stored in the injection system electronic
units or the characteristics of the engine and its fittings, is strictly
prohibited, penalty invalidation of the guarantee and absence of
all liability on the part of IVECO MOTORS.
