English-80
TECHNICAL DATA
Hydraulic System
Max. working pressure - 45 bar / 630 PSI
Transmission
Manufacturer Tuff Torq K 62 Tuff Torq K 66
Oil SAE 10W/30, class SF-CC SAE 10W/30, class SF-CC
Oil volume, total 3.2 litres 3.2 litres
Cutting unit Combi 112 Combi 112
Cutting width 1120 mm / 44" 1120 mm / 44"
Cutting heights 40 - 100 mm / 1.57" - 3.93" 40 - 100 mm / 1.57" - 3.93"
Blade length 420 mm / 16.5" 420 mm / 16.5"
Width 1230 mm / 48.4" 1230 mm / 48.4"
Weight 50 kg / 110 lb 50 kg / 110 lb
Additional weight, ProFlex 8 kg / 17.6 lb 8 kg / 17.6 lb
Length machine with unit 2450 mm / 8.04 ft 2450 mm / 8.04 ft
Cutting unit Combi 122 Combi 122
Cutting width 1220 mm / 48" 1220 mm / 48"
Cutting heights 40 - 100 mm / 1.57" - 3.93" 40 - 100 mm / 1.57" - 3.93"
Blade length 450 mm / 17.7" 450 mm / 17.7"
Width 1330 mm / 52.4" 1330 mm / 52.4"
Weight 60 kg / 17.6 lb 60 kg / 17.6 lb
Additional weight, ProFlex 8 kg / 17.6 lb 8 kg / 17.6 lb
Length machine with unit 2550 mm / 8.37 ft 2550 mm / 8.37 ft
Data Rider ProFlex 18 Rider ProFlex 21
IMPORTANT INFORMATION
When this product is spent and is no longer
used it should be returned to the dealer or other
authority for recycling.
IMPORTANT INFORMATION
In order to introduce improvements the
specification and design are subject to
alteration without prior notice.
Note that no legal demands whatsoever can be
made with the support of the information in this
operator’s manual.
Only use original spare parts with repairs. The
use of other parts invalidates the warranty.
