Illustrated parts catalog 3–3
Item Description Spare Part Number
(1) 18.4-inch, AntiGlare, dual-lamp, display assembly (includes 2 WLAN antenna
transceivers and cables, webcam, microphones, and logo)
498166-001
✎
See “Display assembly components” on page 3-7 for information on display assembly spare part numbers.
(2) Switch cover 496882-001
(3) Keyboard cover (includes LED board and cable) 496883-001
(4) Keyboard (includes cable)
For use in Belgium 496878-A41
For use in Brazil 496878-201
For use in the Czech Republic 496878-221
For use in Denmark, Finland, and Norway 509474-DH1
For use in France 496878-051
For use in French Canada 509474-121
For use in Germany 496878-041
For use in Greece 496878-DJ1
For use in Italy 496878-061
For use in Japan 509474-291
For use in Latin America 496878-161
For use in the Netherlands 496878-B31
For use in Portugal 496878-131
For use in Russia 496878-251
For use in Saudi Arabia 509474-171
For use in South Korea 509474-AD1
For use in Spain 496878-071
For use in Switzerland 496878-111
For use in Taiwan 496878-AB1
For use in Thailand 509474-281
For use in Turkey 496878-141
For use in the United Kingdom 496878-031
For use in the United States 496878-001
(5) Power button board (includes cable) 498325-001
(6) Bluetooth module
✎
The Bluetooth module spare part kit does not include a Bluetooth module cable.
The Bluetooth module cable is available using spare part number 496872-001.
483113-001
(7) Bluetooth module cable 496872-001
Plastics Kit (see “Plastics Kit” on page 3-9 for more Plastics Kit spare part information) 496888-001
(8a) ExpressCard slot bezel
(8b) Hard drive cover
(8c) WLAN module compartment cover
(Continued)
