Tray 2, Tray 3, or Tray 4 detectable standard paper size
The printer can automatically detect most standard sizes in Trays 2, 3, and 4, including
Letter, A3, A4, A5, JIS B4, JIS B5, Legal, Executive, and 11 by 17 inches. Be sure the
Tray 2, Tray 3, or Tray 4 switch is in the Standard size position.
Note
When the tray detects a standard size, only one option will appear in the control panel. To
use a different size, change the width and length guides to the new size or set the tray switch
to custom.
Tray 2, Tray 3, or Tray 4 paper type
1. Press to enter the MENUS.
2. Press
to highlight PAPER HANDLING.
3. Press
to select PAPER HANDLING.
4. Press
to highlight TRAY 2 TYPE, TRAY 3 TYPE, TRAY 4 TYPE.
5. Press
to select TRAY 2 TYPE, TRAY 3 TYPE, TRAY 4 TYPE.
6. Press
or to highlight the desired paper type.
7. Press
to select the paper type.
8. Press P
AUSE
/R
ESUME
to return to the Ready state.
Tray 2, Tray 3, or Tray 4 custom paper
The Tray X size menu will be displayed when the Tray 2, Tray 3, or Tray 4 switch is moved to
the custom size position. You can also change the size setting in the control panel from ANY
CUSTOM to CUSTOM.
Use the ANY setting when the paper on which you want to print does not exactly match the
size of the paper specified in the document you are printing. The printer will look first for
paper that exactly matches the document, and then it will look for and print from the tray set
to ANY.
Use ANY CUSTOM to set a custom size in the software application. The printer will look for
an exact size match. If it does not find an exact match to the custom size specified, it will look
in the tray set for ANY CUSTOM. Finally, the printer will look for and use paper from a tray
set to ANY.
Note
If you will be using only one size of custom paper, or will not be leaving the same custom size
paper in the tray for some time, set the tray switch to Custom and select the size setting in
the control panel to ANY CUSTOM. You do not need to set the unit of measure, X dimension,
or Y dimension.
