Processor
NOTE: All processor spare part kits include replacement thermal material.
Description Spare part number
AMD A8-3510M (2.5-GHz/1.5-GHz, 4-MB L2 cache, 45W) 653358-001
AMD A6-3410M (2.3-GHz/1.6-GHz, 4-MB L2 cache, 45W) 653357-001
AMD A4-3310M (2.5-GHz/2.1-GHz, 2-MB L2 cache, 45W) 653356-001
AMD E2-3000M (2.4-GHz/1.8-GHz, 1-MB L2 cache, 35W) 653351-001
Before removing the processor, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 42).
5. Remove the bottom door (see
Bottom door on page 49).
6. Remove the fan (see
Fan on page 64).
7. Remove the heat sink (see
Heat sink on page 65).
Remove the processor:
1. Position the computer upside-down with the front toward you.
2. Use a flat-bladed screwdriver to turn the processor locking screw (1) one-half turn
counterclockwise until you hear a click.
