Temperature
TemperatureTemperature
Temperature
Operating
Non-operating
14° to 149° F (–10° to 65° C)
–40° to 176° F (–40° to 80° C)
Humidity
HumidityHumidity
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
AltitudeAltitude
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
Configuration UtilityConfiguration Utility
Configuration Utility
4
Microsoft Windows XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
Broadcom IHV extensions for Windows Vista available to support
Cisco Compatible Extensions.
LED Activity
LED ActivityLED Activity
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN
supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows
Vista.
Broadcom 4322AGN
Broadcom 4322AGNBroadcom 4322AGN
Broadcom 4322AGN
802.11a/b/g/draft-n WiFi
802.11a/b/g/draft-n WiFi802.11a/b/g/draft-n WiFi
802.11a/b/g/draft-n WiFi
Adapter
AdapterAdapter
Adapter
Wireless LAN Standards
Wireless LAN StandardsWireless LAN Standards
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (draft 2.0)
*
* The specifications for 802.11n draft 2.0 are draft specifications and are
not final. If the final specifications differ from the draft specifications, it may
affect the ability of the notebook to communicate with other 802.11n WLAN
devices.
Interoperability
InteroperabilityInteroperability
Interoperability
Wi-Fi certified (802.11abg only)
Cisco Compatible Extensions Program compliant (802.11abg only) with
Microsoft Windows Vista and XP (details at:
http://www.hp.com/go/notebooks/WLAN
)
Frequency Band
Frequency BandFrequency Band
Frequency Band
2.4 GHz and 5 GHz
Data Rates
Data RatesData Rates
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (draft): 6, 6.5, 9, 12, 13, 13.5, 18, 19.5, 24, 26, 27, 36, 39,
40.5, 48, 52, 54, 58.5, 65, 78, 81, 104, 108, 117, 121.5, 130, 135,
162, 216, 243, 270, 300 Mbps
Frequency Support
Frequency SupportFrequency Support
Frequency Support
20 MHz: 2.4 GHz and 5 GHz bands
40 MHz: 2.4 GHz and 5 GHz bands
QuickSpecs
HP ProBook 5310m Notebook PC
HP ProBook 5310m Notebook PCHP ProBook 5310m Notebook PC
HP ProBook 5310m Notebook PC
Technical Specifications
DA - 13394 Worldwide — Version 2 — December 2, 2009
Page 23
