Illustrations and Parts Lists
8-51
RH2-5338-000CN Cable, Ribbon, from Paper PCA to
Controller
Figure 8-4 on page 8-14
RH3-2195-000CN Power Supply (100 - 120 V) Table 8-19 on page 8-35
RH3-2196-000CN Power Supply (220 - 240 V) Table 8-19 on page 8-35
RH7-1354-000CN Fan Table 8-8 on page 8-17
RH7-1356-000CN Main Motor Table 8-17 on page 8-33
RH7-5192-000CN Paper Feed Clutch Table 8-7 on page 8-14
RH7-5193-000CN Pickup Solenoid Table 8-18, on page 8-36
RH7-5195-000CN Paper Pick Up Solenoid Table 8-7 on page 8-14
RS5-0695-000CN Tray 2 Shaft Gear Table 8-8 on page 8-17
RS5-1392-000CN Tray 1 and 2 Pickup Shaft Left
Bushing
Table 8-8 on page 8-17
RS5-2225-020CN Roller Spring Table 8-9, on page 8-21
RS5-2431-000CN Transfer Roller Spring (left) Table 8-13 on page 8-25
RS5-2434-000CN Spring Table 8-8 on page 8-17
RS5-2952-000CN Latch Plate Springs Table 8-5 on page 8-10
RS6-0351-000CN Paper Feed Gear Table 8-13 on page 8-25
RS6-0352-000CN Paper Feed Gear Table 8-13 on page 8-25
RS6-0357-000CN Lower Delivery Shaft Gear Table 8-7 on page 8-14
RS6-0367-000CN Delivery Roller Gear Table 8-11 on page 8-22
WG8-5362-000CN Photo Sensor Table 8-14 on page 8-27
WS6-5092-000CN Power Connector Table 8-7 on page 8-14
XA9-0265-000CN Screw, M4x6 W/Washer Table 8-2 on page 8-6
XA9-0267-000CN Screw, M3x6 TP Table 8-2 on page 8-6
XA9-0815-000CN Screw, M3x4 TP Table 8-2 on page 8-6
XA9-0838-000CN Screw, M4x16 W/Washer Table 8-2 on page 8-6
XA9-0974-000CN Screw, Long DC Controller Screws
(M3x25)
Table 8-2 on page 8-6
XB1-2300-607CN M3x6 Screw, Mach., Truss Head Table 8-8 on page 8-17
XB2-6400-607CN Screw, M4x6 Screw w/Washer Table 8-2 on page 8-6
XB4-2300-407CN Screw, Mach., Truss Head, M4x10 Table 8-22 on page 8-39
XB4-7300-807CN M3x8 Screw, Tapping, Truss Head Table 8-23 on page 8-41
XB4-7400-807CN Screw, M4x8 Truss Head Tapping Table 8-2 on page 8-6
XB4-7401-007CN Screw, M4x10 Pan Head Tapping Table 8-2 on page 8-6
XB6-7300-807CN Screw, M3x8 TP Screw Table 8-2 on page 8-6
XD2-1100-322CN E Ring Table 8-2 on page 8-6
Part Number Description Table Number and Page
