Setting up
Understanding printer parts
1 LCD control panel
2 Top cover
3 Printhead cover
4 Ink cartridge cover
5 Simplex unit or optional auto-duplex unit
6 Output bin
7 Tray 2
8 Media level indicators
9 Tray 3 (optional)
10 Tray 3 base (holds Tray 3 and supports the printer)
