DesignJet 2800CP
HP Parts Reference Guide™
www.h
.com/
o/h
arts
Optional Interfaces
Module
J2590-69001 External JetDirect LAN interface module with RJ-45 connector for ethertwist (10Base-T) or 100VG/802.12 input and 3
parallel (DB-25) output connectors
REQUIRES RETURN OF DEFECTIVE PART
J2590-61011 New Part for J2590-69001
J2591-69001 External JetDirect LAN interface module with ethertwist (10Base-T) and ThinLAN (10BASE-2) connectors
J2593-69001 External JetDirect LAN interface module with Ethertwist (10Base-T) and ThinLAN (10BASE-2) input connectors and 3
parallel (DB-25) output connectors - (part of J2593A)
J2594-69001 External JetDirect token ring interface module with DB-9 and RJ-45 input connectors and 3 parallel (DB-25) output
connectors - (part of J2594A)
REQUIRES RETURN OF DEFECTIVE PART
J2594-61011 New Part for J2594-69001
PC Board (Interface)
J2552-69013 LAN and LocalTalk interface - EtherTwist (10Base-T), ThinLAN (10Base-2), and LocalTalk (DIN-8) connectors
J2555-69013 Token ring LAN interface board - DB-9 and RJ-45 connectors
Other Accessories
CD-ROM (Support)
C7769-90066 DesignJet support CD ROM - Version A.04.01 - Has product information, user's manuals, service manuals, diagnostic
software, test drawings, newsletters, and service notes
Cleaning Supplies
C6247A DesignJet cleaning kit - Includes cleaning solution and 20 cleaning rags
Humidor
C6236A DesignJet CP ink system storage container - Holds printheads and printhead cleaners when not in use
Ink System Return Kt
5183-5283 Return kit (Box and instructions) - For returning defective large format printer ink systems covered under CREW
program
Ink and Printhead
C1806A Black ink system - Includes print head, print head cleaner and ink cartridge
C1807A Cyan ink system - Includes print head, print head cleaner and ink cartridge
C1808A Magenta ink system - Includes print head, print head cleaner and ink cartridge
C1809A Yellow ink system - Includes print head, print head cleaner and ink cartridge
C1892A Black UV ink system - Includes print head, print head cleaner and ink cartridge
C1893A Cyan UV ink system - Includes print head, print head cleaner and ink cartridge
C1894A Magenta UV ink system - Includes print head, print head cleaner and ink cartridge
C1895A Yellow UV ink system - Includes print head, print head cleaner and ink cartridge
Kit
C4723-60141 Preventive maintenance kit - Contains line sensor cover, encoder strip, Y-AXIS pulley, belt, motor, cutter, silicon grease,
plastic surface cleaner, synthetic oil and wipes
C4723-60238 Adjustment kit - Includes instructions, empty cartridge, digitizing sight (magnifier) and gauge
Lubricant
6040-0855 Synthetic oil - 4oz (113g) plastic bottle
Manual
5959-9733 HP-GL/2 & HP RTL reference guide - Programming information, handbook for developers
5959-9734 Comparison guide for HP-GL/2 and RTL peripherals (English)
