NEW F-150
ford.ca
TECHNICAL SPECIFICATIONS
FRONT SUSPENSION
Type Coil-over-shock
Axle (rating @ ground) 1,429 kg (3,150 lbs.) – 1,837 kg (4,050 lbs.)
REAR SUSPENSION
Type Solid axle
Axle (rating @ ground) 1,588 kg (3,500 lbs.) – 2,177 kg (4,800 lbs.)
STEERING
Assist Electric power-assisted steering (n/a with 6.2L V8 engine)
Hydraulic power-assisted steering (6.2L V8 engine only)
BRAKES
Type 4-wheel vented-disc ABS
Front (rotor diameter) 351-mm (13.8-in.)
Rear (rotor diameter) 348-mm (13.7-in.)
MECHANICAL
1
Fuel consumption ratings based on Transport Canada approved test methods. Actual fuel consumption may vary.
2
Requires Heavy-Duty Payload Package.
3
Requires Max. Trailer Tow Package.
4
Ford Harley-Davidson
TM
F-150 only.
MAXIMUM PAYLOAD WEIGHT RATINGS kg (lbs.)
REGULAR CAB SUPERCAB SUPERCREW
MAX. 126-in. 145-in. 145-in. 163-in. 145-in. 157-in.
GVWR WB WB WB WB WB WB
4x2
3.5L EcoBoost 3,198 (7,050) — 934 (2,060) 816 (1,800) — — —
3,221 (7,100) — — — — 798 (1,760) 758 (1,670)
3,334 (7,350) — — — — 803 (1,880)
3
—
3,402 (7,500) — — 803 (2,070)
3
— — —
3,425 (7,550) — — — — — 803 (2,000)
3
3,720 (8,200) — 1,388 (3,060)
2
— 1,211 (2,670)
2
— —
3.7L V6 FFV 2,926 (6,450) 776 (1,710) — — — — —
3,039 (6,700) — — 726 (1,600) — — —
3,062 (6,750) — 862 (1,900) — — — —
3,084 (6,800) — — — — 735 (1,620) —
5.0L V8 FFV 3,016 (6,650) 826 (1,820) — — — — —
3,198 (7,050) — 953 (2,100) 826 (1,820) — — —
3,221 (7,100) — — — — 816 (1,800) 753 (1,660)
3,720 (8,200) — 1,388 (3,060)
2
— 1,211 (2,670)
2
— —
6.2L 2-Valve 3,289 (7,250) — — — — 640 (1,410)
4
—
V8 Gas 3,334 (7,350) — — — — 762 (1,680)
3
—
4x4
3.5L EcoBoost 3,266 (7,200) — 907 (2,000) 798 (1,760) — 721 (1,590) —
3,334 (7,350) — — — — — 735 (1,620)
3,470 (7,650) — — — — 889 (1,960)
3
—
3,493 (7,700) — — 943 (2,080)
3
— — 857 (1,890)
3
3,720 (8,200) — 1,297 (2,860)
2
— 1,107 (2,440)
2
— —
3.7L V6 FFV 3,016 (6,650) 758 (1,670) — — — — —
3,130 (6,900) — — 685 (1,510) — — —
3,153 (6,950) — 844 (1,860) — — — —
5.0L V8 FFV 3,084 (6,800) 780 (1,720) — — — — —
3,266 (7,200) — 925 (2,040) 762 (1,680) — 708 (1,560) —
3,334 (7,350) — — — — — 712 (1,570)
3,720 (8,200) — 1,256 (2,770)
2
— 1,070 (2,360)
2
— —
6.2L 2-Valve 3,334 (7,350) — — — — 558 (1,230)
4
—
V8 Gas 3,493 (7,770) — — — — 803 (1,770)
3
—
3.5L 4-VALVE
3.7L 4-VALVE V6 ECOBOOST
TM
V6 5.0L 4-VALVE V8 6.2L 2-VALVE V8
Configuration Ti-VCT DOHC Ti-VCT DOHC Ti-VCT DOHC VCT SOHC
Fuel injection Sequential Direct Sequential Sequential
Electronic Injection Electronic Electronic
Engine control system Electronic Electronic Electronic Electronic
Induction system Naturally aspirated Twin-turbocharged, Naturally aspirated Naturally aspirated
intercooled
Battery 12-volt; 750-CCA/ 12-volt; 750-CCA/ 12-volt; 750-CCA/ 12-volt; 750-CCA/
78-amp-hr 78-amp-hr 78-amp-hr 78-amp-hr
Cooling system Pressurized Pressurized Pressurized Pressurized
series flow series flow series flow series flow
Cylinders 6 6 8 8
Cylinder head Aluminum Aluminum Aluminum Aluminum
Block material Aluminum Aluminum Aluminum Cast iron
Bore/Stroke 3.76-in./3.41-in. 3.64-in./3.41-in. 3.63-in./3.65-in. 4.02-in./3.74-in.
Compression ratio 10.5:1 10.0:1 10.5:1 9.8:1
Horsepower/rpm 302 @ 6,500 365 @ 5,000 360 @ 5,500 411 @ 5,500
Torque lb.-ft./rpm 278 @ 4,000 420 @ 2,500 380 @ 4,250 434 @ 4,500
Recommended fuel Regular unleaded Regular unleaded Regular unleaded Regular unleaded
or E85 or E85
Transmission 6-speed auto. 6-speed auto. 6-speed auto. 6-speed auto.
with tow/haul with tow/haul with tow/haul with tow/haul
Estimated Fuel Consumption Ratings
1
L/100 km (mpg)
w/6-speed automatic
4x2 city 12.9 (22) 12.9 (22) 13.9 (20) —
4x2 hwy. 8.9 (32) 9.0 (31) 9.7 (29) —
4x4 city 13.4 (21) 13.9 (20) 15.0 (19) —
4x4 hwy. 9.8 (29) 9.4 (30) 10.5 (27) —
w/SelectShift Automatic®
4x2 city 12.8 (22) 13.0 (22) 14.1 (20) 16.9 (17)
4x2 hwy. 8.9 (32) 9.1 (31) 9.8 (29) 11.4 (25)
4x4 city 13.4 (21) 14.0 (20) 15.0 (19) 18.3 (15)
4x4 hwy. 9.8 (29) 9.5 (30) 10.5 (27) 12.7 (22)
POWERTRAINS
